OBJECTIVE: To perform transient structural analysis on a worm gear mechanism rotate the worm so as to get to almost the end of the half-cut and get the required result in ANSYS. PROCEDURE: Open Ansys Workbench and choose transient structural. In the Engineering data, let the material be structural steel. For…
Subham Chauhan
updated on 02 Apr 2021
