Drafting of various geometries using Chamfer, Fillet tool in AutoCad

ans---AIM -

DRAFTING OF VARIOUS GEOMETRIES USING CHAMFER ,FILLET TOOL IN AUTO DAD.

---INTRODUCTION-

Autocad offers various tool to perform diffrent task,these tools are - modification tool ,chamfer fillet ,offset ,rotate ,object snapping ,

trim ,extened, lenthan , mirror and join.





--GEOMETRIES USING DECIMAL SYSTEMOF UNITS .

--PROCEDURE -

 TYPE 'UN' press enter  ,select unit in decimal .





- type l command , enter  ,

 specify start point 1,1

 specify next point @3,0 ,

specify next point@2.12<45        , next point @2.83<135                  ,next point @-2,0                   next point @0,-2

next point is @0,-2.5 than

type L for line press enter

specify start point .

next point @1.5,0         ,next point @0,1        ,next point @0,1.5



type c press ,enter ,

specify center point of circle ,

specify radius .6



type c , specify center point circle ,

specify radius .40

delete another line  .

geometry using decimal is complete .





2.  unit - enter architectural unit .

type L for line and enter .

specify start point 2,5

specify next point @ 2'-10<45            , next point @0,1'-9"    ,next point@-8',0

next point @0,-2'5"

switch polar tracking of 30,60,90

place cursor 30degree  and type 2'-6"

RESULT -



GEOMETRY USING ARCHITECTRUL UNITS IS COMPLETE.





----ENGINEERING UNIT

TYPE UN and put engineering unit .

type 'rec' place enter

specify 1st corner point ,  enter D

lenth5'-.1"

width enter  3'-3"

specify other corner point.



type cha or chamfer in command line ,enter

enter distance .

 specify 1st chamfer dis        2'-3.5"

  second chamfer dis.    ; 1'-9"



select both line

type l  command line ,enter

specify start point ;@1'-3"

specify next point @1'-6"

type c press enter.

center point specify .

specify diameter of circle 1'-6"



delete unwanted line

dli command used for diamension.





result -geometry using engineering units complete .







Q  ---procedure -

type UN and enter decimal unit

type l and enter

specify 1st point 1,1 ,next point  @3,0    , next point @ 0,-.5                  next point @2.5,0              next point @0,2.5



next point @ -2,0        next point @0,3           ,next point @-2.5,0                 ,next point @   0,-2.5 specify .

type l and enter

specify 1st point ,

specfy next point @0,3

next point @1,0 enter

type dli in command ,enter .give diamension.

RESULT --GEOMETRY USING DECIMAL UNIT COMPLETE.







Q--procedure--

Type un ,give enter decimal unit .



type REC command and enter ,

-specify 1st corner of reactangle

enter diamension

length 3

width 6

specify other corner .

type L for line

specify 1st point

specify next point @1.5,0

next point @0,6

on mid point object snap.

type C press enter .

radius .5

 type offset  on command and enter ,

 offset value .5

-select circle to off set ,and click outside circle .

type REC ,press enter ,

specify 1st point corner .

enter diamension

lenth ;5.5

widh :6

specify other corner .

trim and eraseunwanted line .

  type co ,enter

select reactangle abcd and clicl D for displacement  and type @ 8.5,0

- specify base point asa and click enter

DLI for dimlinear on command line ,enter .

result - geometry using  decimal units is complete .





Q- procedure -



type rec in command  ,enter

specify 1st corner of reactangle e

enter D

give lenth 1.5

width .5

specify other corner point



type rec and pres enter

specify 1st corner of rec.

enter diamension

length .5

width 1.5

specify other corner point .



type CO ,enter .

select upper reactgle and click d for displacement ,type @0,.5

 specify base point ,click enter .



type l command line press enter

specify 1st point , next point  @0,-.5

next point @1.5,0             ,next point @ 0,1.5   ,nextpoint @-.5,0       next point @ 0,-1

next point@-1,0    specify .



type L and press enter .

join strat point and next  point.



type REC ,press enter .

specify 1st point

enter diamension

lenth.5

width 1.5

specify other corner .

type REC , press enter .

specify 1st corner of reactanle as b .

enter diamension.

length ;1.5

width .5

specify oTYPEther corner



type co ,enter.

selt reactangle and displacement  type @0,.5

 specify base point ,enter .



result ';

geometry using decimal unit complete .





Q.PROCEDURE

TYPE C PRESS enter'

specify center point 5,5

specify radius 2



open offset and enter

give offset distance 5

select object to fffset clik outside circle

type L command ,enter

specify 1st point 5,5

specify next point @8.55,0





tppe o, command line ,enter

off distance .9

select object to offset clik top and bottom

close figure with 2 lines both sides.





trim and erase  top  and bottom line



type C and press enter  specify center point a

radius .45

type c press enter

 specify center point

radius .45



from draw panel  selt start menu  and radius potion arc menu

specify start point and end point .

radius of arc .90

from draw panel  select start end option  from arc .

specify start point and end point

radius of arc .9

object snap turn on tangent

draw line start point e to  top of big circle and same procedure for other point

draw tangent top and bottom big circle .



trim unwanted line

RESULT -THE GEMETRY USING DECIMAL UNITS IS COMPLETE
