1. Concrete Mix Design for M35 grade concrete with fly ash :- Solution :  Stipulations for Proportioning Grade Designation : M35 Type of Cement : OPC 43 Grade conforming to IS 8112 Type of mineral admixture : fly ash conforming to IS 3812-(Part-1) Max. nominal size of aggregate : 20 mm Min. Cement…

Sketch a G+1 floor residential plan, according to Vaastu Shastra, and list down the names of the structural drawings required to be provided to the site for construction. Also, assume the sizes of the structural elements (Column, Beam, Slab, etc.,) and accordingly calculate the individual corresponding loads from the members…

Create the geometries from P1 to P2 using all the coordinates system methods. You need to use the Line tool to create the geometries. Where required you need to use the circle tool. P1 : Absolute Coordinate Method : Use Line command then enter the coordinates as per the figure given.  Enter Point 1 = (2,1) Enter Point…

Aim & Introduction : Creating a Floor plan, Footing detail and Isometric view of the given drawings using AutoCad. Drawing 1 : Procedure : Enter Line command : L Line Specify the first point : 0,0 Press F8  Line Specify the next point or [Undo] : 0.30 (Move mouse in Right Direction) Line Specify…

Aim & Introduction : Drafting of various geometries using Chamfer, Fillet tool in AutoCad. Drawing 1 : Procedure : Enter Line command : L Line Specify the first point : 0,0 Press F8 Line Specify the next point or [Undo] : 3 (Move mouse in Right Direction) Line Specify the next point or [Undo] :…

1. Residence Plan: Sketch the layout of a residence as shown in the Figure 1. Consider all dimensions as reference to sketch the unit plan. Also the text in the layout are only for reference. Assume the missing dimensions. Also, refer the schedule for size of the doors. Aim: Sketch the layout of a residence as shown in…

                                                                                           …

Aim 1 : Draw the elevation and details of a wardrobe. Procedure : Use Commands: Line Fillet Offset Trim Mirror Dim Mtext Steps: Using all command first Draw the Front Elevation as given. Now Draw the Carcase Elevation as given. Draw the Side Elevation as given. Draw Section-1 as given in the figure. Draw Section-2 as given…

Aim: Creating a Layout, Section and Elevation with dimensions using AutoCAD. Introduction: Create the Plan and Sections as shown in the Figures. Use proper dimension techniques and dimension styles to document the project. Assume the sizes of the doors and windows as per construction standards. Refer to sections for stair…

Aim: Design and Draft a layout of a residential building Introduction: Develop the following: 1. Architectural Drawing (Floor Plan, Elevations, and Sections)                                  2. Structural Drawing (Column, Bean, Footing…

Aim 1: Create the templates as shown in Figures. Introduction: Take the size of the title block as per industry standards or you can assume it as per the size of the paper. Use text and attributes wherever required. After creating the title block you need to save it as a block with names: Custom1_titleblock and Custom2_titleblock,…

Aim 1 : Create the layouts of the Kitchen and provide hatches pattern as shown. Introduction: Create the layouts of the Kitchen and provide hatches pattern as shown. Also, use blocks wherever required. Provide appropriate dimensions in the plan. Assume the size of doors, appliances and others as per the standards. Procedure…

Aim 1: Create a 3D Furniture element as shown in the Figure. Assume dimensions which are missing. Procedure: Draw the lines in CAD as per the given figure. line starting point (0,0,0),(@0,3',0),(@3',0,0)&(@0,-3',0). press esc. Enter offset command of value 2" given in figure. Fillet the internal lines. now close the…

Aim 1: Create a layout of the Plan and Section A of the project in Challenges 7, using the template Tutorial-mArch.dwt in a scale as given in the Figure. Introduction: Use the MV command to create the viewport of the size as shown in Figure. Also, use ATTEDIT command to edit the information in the title block. Use A1 size…

Aim 1: Create a 3D Isometric View of the building with plan and elevation given. Procedure: Draw the plan outline using line tool. Draw the walls of 9" as given in the figure. Now Draw the windows at the given distances in the figure. Dimensioning the plan. now turn on the 3D modeling. Now with 3DFACE command make the…

Aim 1: From the file menu, create a new project (Structural / Architectural / Construction template ) and name the project appropriately Introduction: Open the Revit software and create the new project in it and name the project by saving it in the system. Procedure: Open Revit Software. Click on the New in Model tab to…

Aim : Create a 3 dimensional model of the residential building with a rendered view.   Solution: Draw the G+1 Residential plan. Now Extrude the Ground Floor walls. Now make the openings of the doors and windows on the Ground Floor. Noe Draw the glass of the windows and doors to door frames. Now draw the staircase. Now…

Aim 1: What is BIM? Summarize the features of BIM and benefits of using BIM over 2D CAD tools. Solution: BIM is the visual representation of the physical and functional characteristic of facility from inception onwards. It Serve as a shared information repository for collaboration throughout a facilities life cycle.  …

Aim 1: Use the project file created from Week 2. Use it for this assignment. Based on your layout from week 2, using floor tool under architecture tab and select the floor with appropriate material and thickness using the property browser create a layout in the Ground floor Level. Align the floor plan with grids created…

Aim 1: Based on the project saved from Week 3, proceed from the First Floor Level. Model a Ceiling from the architecture tab above the walls at the first-floor level. Procedure: open the First Floor Ceiling Plan. Select the Ceiling tool in Architectural tab. Draw the Ceiling for Bed room 1. Now again choose the ceiling…

1) Why are building codes or standards essential for the modeling/ efficiency of drawings in Revit ? Solution: The National Building code is a document that provides guidelines for construction of structures like Residential, Institutional, Educational, Commercial, Assembly & Storage Spaces. It is Important to follow…

1) Open an architectural template. Using the Manage tab set project base point and project shared coordinates for the project Procedure: Open Revit new Architectural template. Draw grids  Select the grid tool in architecture tab. Draw one horizontal and one vertical grid in the work plane. Go to the drop down of the…

1) Select the type of structure you want to build from one of the three below:        a. Multi-Unit Residential Apartment        b. Office Buildings        c. School   Solution: Multi-Unit Residential Apartment     2) Assume reasonable assumptions…

1) Using Dynamo create a set of sinusoidal points and create a curve and create a surface out of the curve. Solution: Open Revit New File. Go to Manage Tab and click on Dynamo. Select New in the Dynamo. insert the Integer Slider. Making three integer Slider. Copy the First one and paste it 2 times. Enter the values in…

1. 1. Write the steps involved to upload a .std file through web mail? Solution: Open the STAAD Pro and Select the share option available on the home screen. Select send mail option. Then select the Std file from the saved location & send it. 2. Name the different materials that can be designed using STAAD Pro. Solution:…

1. 1. How will you assign Circular section to column? Solution: Create a New File in Staad Pro. Now Create 2 nodes in Y direction. Now join the Two nodes using beam option to create the column Member. Now go the Properties tab. Select the Define command. Property dialog box will open. Enter the Diameter of the Circular…

1. 1. State the primary load cases to be considered for design. Solution: The Primary Load cases to be considered for design is Dead Load & Superimposed Deal Load.   2. What is One – Way slab? Solution: One Way Slab = ( Lx ÷ Ly ) > 2 is this condition satisfy then the slab is…
