MIX DESIGN FOR M35 GRADE OF CONCRETE WITH FLY ASH : 1. Collected data:  Grade of deisgnation: M35  Type of cement used : OPC-43 grade comfirming to IS 8112 Mineral admixture used: Fly ash Confirming to IS 3812 part 1 Max. nominal size of agg.: 20mm Minimum cement content: 340 Kg/cub. m (From talble 5 of IS 456-2000 Exposure…

ANSWERS: G+1 RESIDENTIAL BULIDING PLAN ACCORDING TO VAASTU SHASTRA:                 GROUND FLOOR                        1ST FLOOR PLAN Detailing of building elements: Size of column: 300mm*300mm Size of column: 300mm*450mm…

AIM: DRAW GIVEN GEOMETRIES BY USING CO-ORDINATE SYSTEMS. INTRODUCTION: THIS CHALLENGE INCLUDES STUDY ABOUT HOW TO DRAW GEOMETRIES USING CO-ORDINATE SYSTEM. PROCEDURE:  1. Sets unit. 2. For drawing line, use command "line".  3. Give input in format like (x,y), (@x,y) and (@unit<angle). 4. Draw cicle by using…

1. Aim: Drawing of load bearing wall over spread footing geometry uisng autoCAD. IntroductionL:   In this challenge apllicaiton of sketching and modifying tools are used for drawing of different geometries. Stepwise Procedure:   Set units according to requirements. Draw geometry by using sketching…

answer file will be attached.

1.0  AIM: Sketching of layout of residential building hy using autCAD. INTRODUCTION: In this challenge, application of all drawing tools and modification tools are used for sketching of layout of residential building. PROCEDURE:  -Set limits by using commands "limits". -Set units by using commands "unit" as engineering…

1.0  AIM: Creation of column shcedule in autoCAD software. INTRDUCTION: In this challenge, brief detailing about how to make table, column schedule and other text working is done.  PROCEDURE: Following steps are used for drawing of column shcedule.  For drawing of column section, use rectangle tools, offset…

1.0  AIM: Application of autoCAD to draw wardrobe drawing with detail information.  INTRODUCTION: In this challenge, application of drawing and modifying tools for drawing of wardrobe, building layouts, structural drawings and different schedules is used.  PROCEDURE: Following steps are used for drawing…

1.0  AIM: Application of autoCAD to draw plan, elevation and section of building.  INTRODUCTION: In this challenge, application of drawing and modifying tools for drawing of plan, elevation and section of building.    PROCEDURE: Following steps are used for drawing of plan, elevation and section…

AIM: Application of autoCAD to make drawings of building with dimension 20'*60' such structural drawings, plan, elevation and section of building. INTRODUCTION: In this project, application of autoCAD is used to build plan of house, to make structural drawing beam and column, to make elvation of building and…

1.0  AIM: Creation of templete using attributes and blocks tools.  INTRODUCTION: In this challenge, creation of templete done in addition to other tools use of attribute and block is involved.  PROCEDURE: Following process is followed for creation of templete using attribute and block.  - With…

1. AIM: Application of autoCAD to Layout of kitchen with including hatching and others detail information.  INTRODUCTION: In this challenge, application of drawing and modifying tools for drawing of layouts, elevation and section is used and in advanced hatching related work is done.  PROCEDURE: Following…

 1.0 AIM: Application of autoCAD to draw plan, elevation and section of building and making it as layout for ploting purposes.  INTRODUCTION: In this challenge, application of drawing and modifying tools for drawing of plan, elevation and section of building and making it as layout for ploting and printing…

1.0  AIM: Drawing of 3D modeling of given furniture with the help of autocad.  INTRODUCTION: In this challenge, drawing of 3D modeling is done with the help of 3D drawing tools, UCS and modifying tools. PROCEDURE: Following steps are carried out to draw isolated footing as 3D.  - Set units and limits. -…

1.0  AIM: Drawing of 3D model of building using autocad software.  INTRODUCTION: In this challenge, use of 3d tools and 2d tools are used very professionally to create building section, elevation, 3D of building parts etc.  PROCEDURE: Following procedure is followed to draw 3D models of building. …

AIM: Creating a 3D rendered model for a Residential Building OBJECTIVE: Creating a 3D rendered model for a Residential Building using AutoCAD  INTRODUCTION: Several types of 3D modeling are available in AutoCAD. Wireframe modeling is useful for initial design iterations and as reference geometry, serving…

1) AIM: To create a new project (Structural/Architectural/Construction template) and naming the project appropriately. INTRODUCTION:  Revit is a BIM software helping architectural, engineering, and construction (AEC) teams to create high-quality buildings and infrastructure. We use Revit to Model shapes,…

1. AIM: To understand the concept, Features and benefits of BIM.  INTRODUCTION: This challenge covers the points as follows  - Concept of BIM, Features and benefits of BIM.  - Drawing of levels and grid - Drawing layout of residential building, annoatate it and inserting furniture to the model. …

1.0 AIM: To create a floor plan and need to apply the materials and thickness using the property browser and to align the floor plan with grids creation. INTRODUCTION:  In this challenge drafting of floor, wall, multistory buildings, adding furnitures, adding other accesories is done with proper direction.  By…

1.0 AIM: To create ceiling elements to building model in revit software.   INTRODUCTION: In this challenge information and folllowing building elements modeling is done with proper explaination.  - modeling of ceiling element to building - Modeling roof of building and changing properties. …

1.0 Ans: In this project I am going to build an office building  It comes under Group E : Business Buildings according to NBC This type of buildings are constructed for carrying out business related activities. The main purpose of such buildings is to carry out business transactions, keeping of…

1.0 AIM: To create the sinusoidal points and create a curve and surface out of the curve.  INTRODUCTION: In this project Basics of dynamo and parametric design using revit is explained with some examples.  Dyanamo is virtural programming software used to design parametric geometries. We can also by fixing…

 1.0 AIM: To use the Architecture/ Structure Project file developed in Week 6 to 8 .Export the Revit architecture and structure model to Navisworks Cache file following the export settings.  INTRODUCTION: In this project basics of NAVISWORK software tools is explained. Following points are covered with practically…

Question1: 1.0 AIM:  To analyse the mode of failure or damage of the beams in the pictures.     INTRODUCTION: In this challenge, theory related the failures of structure is explained. With that type of failures, observations of image and state of the structural elements like it is repairable or…

1.0  AIM: To differentiate static and dynamic analysis.  INTRODUCITON:  In this week basics of structural dynamics analysis is covered with explaination the following topics.  - Differentiation between static and dynamic analysis - Force displacement graph for linear elastic as well as for linear…
