DESIGNING AN AMERICAN CHOPPER USING SOLIDWORKS INTRODUCTION     This report contains an explanation for designing an American chopper using solidwork software. This helps to know how to use the basic tool, 3D modeling, Assembling, and Rendering in Solidworks OBJECTIVEThe main objective of this course is…

  DESIGNING AN SUNSEEKER PREDATOR YACHT USING SOLIDWORKS INTRODUCTION      This report contains an explanation for designing a Sunseeker Predator Yacht using solidwork software. This helps to know how to use the tool, 3D modeling, Assembling and Rendering in Solidworks OBJECTIVES     …

DESIGNING A CASING USING NX CAD Objectives          The report contains a detailed explanation of sheet Metal Design of Casing. The main objective of this course is to learn Sheet metal modeling, and also exploring most of the basic tools in NX Cad INTRODUCTION         …

DESIGNING A BOX ASSEMBLY USING NX CAD   OBJECTIVE       The report contains a detailed explanation of sheet Metal Design of Box assembly using NX cad software. INTRODUCTION       Sheet metal Design is the process of making thin sheet metal into different forms done by the of…

SHEET METAL DESIGN OF BRACKET USING NX CAD   OBJECTIVE       To design a sheet metal Bracket by using siemens NX cad software. INTRODUCTION       Sheet metal Design is the process of making thin sheet metal into different forms done by the of NX cad software. This helps to know…

SHEET METAL DESIGN OF ODD SHAPED BOX ASSEMBLY USING NX CAD   OBJECTIVE       To design a sheet metal odd shaped box assembly by using siemens NX cad software. INTRODUCTION       Sheet metal Design is the process of making thin sheet metal into different forms done by the of…

DESIGNING SHEET METAL BRACKET-II OF USING NX CAD   OBJECTIVE       To design a sheet metal Bracket by using siemens NX cad software. INTRODUCTION       Sheet metal Design is the process of making thin sheet metal into different forms done by the of NX cad software. This helps…

BENCHMARKINGBenchmarking is defined as the process of measuring products, services, and processes against those of organizations known to be leaders in one or more aspects of their operations. Benchmarking provides necessary insights to help you understand how your organization compares with similar organizations, even…

UNDERBODY COATING           Cars around the world are driven in different conditions such as sand, road,mud and snow, the under surface of the vehicle is prone to damage like scratches, corrosion, stone chipping etc. Underbody coating helps in protecting the under surface of the vehicle and…

DESIGN OF HOOD ASSEMBLY OBJECTIVE The main objective of this project is to design the hood assembly of the car using NX cad. The parts of the hood assemblys are hood outer surface, hood inner surface, striker, hinges. This design consist of opening angle of the hood and Safety factors. INTRODUCTION The hood or bonnet is…

OBJECTIVE        To calculate the section modulus of the hood assembly and modify the sketch to improve the section modulus on the hood assembly using NX cad. INTRODUCTION        The Section modulus is a geometric property for a given cross-section used in the design of flexural…

OBJECTIVE The main objective of these projects is to design a front fender from given skin data and the master section provided with drip, bumper, A-pillar, splash, and sill mounting areas in NX cad. FENDER           Fender is the American English term for the part of an automobile, motorcycle,…

OBJECTIVE         To design the Front roof rail, Bow roof rail, Center roof rail, and Rear roof rail using the given roof styling and the master section using the NX cad. To calculate the Heat distortion criteria and Snow load criteria on the designed roof. Roof       An automobile…

OBJECTIVE To design the back door assembly of a car using the given skin data and also design the back door inner panel, hinge reinforcement, gas-stay reinforcement, wiper motor reinforcement, latch, and striker reinforcement using NX-cad software. INTRODUCTION The back door is used to access the boot space of the car.…

TOOLING AXIS, DRAFT ANALYSIS OF FAN COVER OBJECTIVE      The main objective is to find the Tooling axis and Draft analysis of given Class A surface of the fan cover. DRAFT      Draft is the amount of taper for molded or cast parts perpendicular to the parting line.When developing parts for…

TOOL AXIS, DRAFT ANALYSIS OF BASE BRACKET  OBJECTIVE   The main aim objective is to create tooling axis for Class-A surface, Class-B surface and Class-C surface of Base Bracket. Create a solid model from the surfaces and Draft analysis of Class-A surface and Solid model of the Base Bracket. DRAFT Draft is the…

TOOL AXIS, DRAFT ANALYSIS OF SWITCH BEZEL OBJECTIVE   The main aim objective is to create tooling axis for Class-A surface, Class-B surface and Class-C surface of Switch Bezel. Create a solid model from the surfaces and Draft analysis of Switch Bezel solid model. DRAFT Draft is the amount of taper for molded or cast…

TOOL AXIS, DRAFT ANALYSIS OF DOOR ARM REST OBJECTIVE   The main aim objective is to create tooling axis for Class-A surface, Class-B surface and Class-C surface of Door Arm Rest. Create a solid model from the surfaces and Draft analysis of Door Arm Rest solid model. DRAFT Draft is the amount of taper for molded or…

TOOL AXIS, DRAFT ANALYSIS OF COIN HOLDER OBJECTIVE   The main aim objective is to create tooling axis for Class-A surface, Class-B surface and Class-C surface of Coin Holder. Create a solid model from the surfaces and Draft analysis of Coin Holder solid model. DRAFT Draft is the amount of taper for molded or cast…

CORE AND CAVITY DESIGN FOR SWITCH BEZEL Objective The main objective is to create design Tooling axis, Class-B surface and Class-c surface from given Class-A surface , solid model from surfaces, Draft analysis and also create Core and cavity blocks for the Switch Bezel.  TOOLING AXIS      It is defined…

DESIGN RIB ON THE COIN HOLDER USING CATIA Objective To design the Ribs for the coin holder considering the designing rules. Ribs Ribs are a feature in plastic injection moulded parts. They are thin extensions that run perpendicular to a wall or plane. They are commonly used to additional support and strength to a part. …

DESIGNING SCREW BOSS AND DOG HOUSE FOR THE COIN HOLDER Objective To design the screw boss and dog house for the coin holder considering the design rules. Screw boss Boss features are commonly found in injection moulding designs. They are used to aid in the assembly of molded parts by providing a channel for a screw. Designing…

DESIGN THE LOCATORS AND HEAT STAKE TO DOOR APPLIQUE OBJECTIVE To design the Locators and Heat stake from the door applique form the Class-A surface, Class-B surface, Class-C surface and Draft analysis for class-A surface and final model. Heat stake  Heat Staking is a pulsed-heat process to join two or more parts out…

B-PILLAR DESIGN THROUGH MASTER SECTION DEVELOPMENT OBJECTIVE The main objective is to develop closed surface model using master section and develop engineering features like Ribs, Dog house, and Locator to the model , create tooling axis ,lifter axis and Draft analysis of Class-A and final model of the B-pillar. Steps…

Objective  The main objective is to design the part models and assembly of Quick return mechanisum and CV joint. Quick return mechanisum        CV joint

OBJECTIVE To create Door interior parts from the given data of class-A surface along with master section by the following the design rules using catia v5. INPUT DATA  Door Interior has 4 components 1. Door arm rest 2. Lower substrate 3. Map pocket 4. Map pocket substrate   The input class-A surface is containing…

OBJECTIVE The main is to Create 1D elements on the following component with given cross-section and DOF. Given Data a. Rod element:- Translational DOF should be Constrained with RBE2 link Cross-Section: BOX- Dimension a= 12 mm                        …

Aim: To write a program in matlab to simulate the forward kinematics of a 2R Robotic arm and Create a movie from the plots obtained from the program.   Matlab Code % program for 2R Robotic Arm Challange clear all close all clc %inputs l1=1; l2=0.5; theta1=linspace(0,90,12); theta2=linspace(0,90,12); ct=1; for i=1:length(theta1)…

OBJECTIVE  The main objective of this challenge is to extract the midsurface and generate mesh on the hood surface using hyperworks. GIVEN MODEL     QUALITY CRITERIA S.N Quality Criteria  Value  1 Aspect Ratio  5 2 Skewness 45 3 Warping 15 4 Taper      0.5 5 Min. Length 2 Units…

OBJECTIVEThe main objective of this challenge is to write a program that can solve the second order ODE of a simple pendulum and make the animation for the pendulum in terms of angular displacement.   CODE %program for simple pendulum clear allclose allclc %parametersb =0.05;g = 9.81;l = 1;m = 0.1; theta_0 = [0; 3];t_span…

AIMTo study about Genetic Algorithm and to calculate the global maxima of stalagmite function using Genetic Algorithm in MATLAB. OBJECTIVETo study about Genetic Algorithm and stalagmite function.To write a code in Matlab to optimise the stalagmite function and find the global maxima of the function.To plot graphs based…

AIM:        To write a code in MATLAB to parse the NASA thermodynamic data file and then calculate thermodynamic properties of various gas species. Objective: Write a function to extract 14 coefficients and calculate Enthalpy, Entropy, Specific heat & molecular weight for all the species in the data file. Plot Cp, Enthalpy,…

Aim To create a program that simulates the state points of a rankine cycle from the inputs by user ad calculates the peformance parameters such as thermal efficiency, Back work ratio, turbine and pump work. Theory The Rankine cycle is a model used to predict the performance of steam turbine systems.Rankine cycle consits…

Aim- To Create a Teramesh for given models with the respective quality criteria given.  Objectives- Perform a proper geometric clean up on the surfaces.  To Create a 3D Tetramesh with the respective quality criteria given. Model 1. Import the given geometry file in the Hyperworks. Press the 'F' key…

OBJECTIVE:To mesh the given geometry and create 1D connectors at desired locations using Hypermesh. The following connections have to be realized in each respective component 1. Right_Rail_2 & Front_truss_1:- Seam-Quad(angled+capped+L) 2. Left_Rail_2 & Front_truss_1:- Quad elements 3. Front_truss_2,…

AIM: To define the Electrical properties of the given components.    PART - 1: DEUTSCH DT06 - 08SA: CONNECTOR SIDE: BUNDLE SIDE :   PART - 2: TYCO 174357 - 2: CONNECTOR SIDE: BUNDLE SIDE :     PART - 3: TYCO 85229 - 1: Define the object as the Mounting equipment. Then define the same as a…

  Aim: To  extract a mid surface and mesh the  given component.   Given model: Procedure:   1. To geometrically clean the model for any error on it.  2. To extract a mid-surface of the component.   3. To clean and defeature the Midsurface so as to avoid any minimum…

Aim: To  extract a mid surface and mesh the  given component.  Target Element Length = 4 Units S.N Quality Criteria  Value  1 Aspect Ratio  5 2 Skewness 45 3 Warping 15 4 Taper      0.5 5 Min. Length 2 Units 6 Max. Length 6 Units 7 Min angle Quad 45 8 Max angle Quad…

Q1. Download following cad data & define it as Electrical support using Electrical Part design Workbench. Define all the necessary properties. process: Create two points one as entry and another as exit point. create planes at two points and another at base. Switch to Electric part desgn Click on support defination…

Aim:  1) To Route the following harness layout in the Electrical workbench. 2) Add protective covering on all branches connected to connectors. Given: CAD data of the following Connectors:  DT06-4S DT06-6S DT06-2S DT06-08SA Connectors Layout Design 1. Download connector 3D data from www.te.com DT06-4S…

Aim: Route two electrical harnesses per the given layout and interconnect them as a single harness assembly check for bundle continuity, and bundle warnings, and then provide annotations for the final harness assembly. Objective: The objective of this project is to first route the two Harness A and Harness B as per the…

AIM: TO FLATTEN THE WIRING HARNESS AND DRAFT THE WIRING HARNESS ASSEMBLY. GIVEN: HARNESS FLATTENING:   DRAFTING REPRESENTATION
