SOLVING SECOND ORDER ODE USING MATLAB.   CONTENTS: Objective. Theory explaining simple pendulum. Program. Errors. Result and link for the animation. Conclusion.   OBJECTIVE: To write a proram to stimulate trasient behaviour of a simple pendulum and to create an animation of its own.     And the other…

WRITING A CODE TO OPTIMISE THE STALAGMITE FUNCTION AND FIND THE OPTIMUM VALUE OF THE FUNCTION. CONTENTS: EXPLANATION OF GENETIC ALGORITHM. SYNTAX OF GENETIC ALGORITHM. CASE1. PROGRAM1. OUTPUT1. CASE2. PROGRAM2. OUTPUT2. CASE3. OUTPUT3. PROGRAM3. ERRORS. RESULT. CONCLUSION.            EXPLANATION…

FILE PARSING OF NASA THERMODYNAMIC DATA  AIM: To execute file or data parsing from the nasa thermodynamic data file. FILE PARSING DEFINITION: Parsing is the process of analyzing a string or symbol, either in natural language, computer languages or data structurtes conforming to the rules of a formal…

RANKINE CYCLE SIMULATOR USING MATLAB.   AIM: To create a Rankine cycl simulator using Matlab and calculate the state points based on the user inputs. And also plot the T-S and H-S relation diagram. CONTENTS: EXPLANATION OF RANKINE CYCLE. IDEAL RANKINE CYCLE DIAGRAM. TERMINOLOGIES USED. PROGRAM. STEP-WISE EXPLANATION…

Simulink model of Doorbell using solenoid block and Usage of a thermistor to sense the temperature of a heater & turn on or turn off the fan as per user conditions. 1.)Simulink model of Doorbell using solenoid block : Aim: To create a simulink model of a doorbell using a solenoid block.…

Draft: In engineering, Draft is the amount of taper for molded or cast parts perpendicular to the parting line. It can be measured in degrees or mm/mm (in/in) .The manufacture of a part that incorporates zero or negative angles may require a mold that can be separated into two or more parts, in order to release the…

  Color code: Final closed surface: Iso view: Front View: Side view: Top view: Tree structure:

 Switch Bezel Plastic component through the given Class-A surface:  Draft Analysis: The Draft Analysis command enables you to detect if the part you drafted will be easily removed. This type of analysis is performed based on color ranges identifying zones on the analyzed element where the deviation from…

 Coin Holder Plastic component through the given Class-A surface:  Draft Analysis: The Draft Analysis command enables you to detect if the part you drafted will be easily removed. This type of analysis is performed based on color ranges identifying zones on the analyzed element where the deviation from…

Report of Draft Analysis and tooling axis creation: Draft: In engineering, Draft is the amount of taper for molded or cast parts perpendicular to the parting line. It can be measured in degrees or mm/mm (in/in) .The manufacture of a part that incorporates zero or negative angles may require a mold that can be separated…

Draft Analysis: The Draft Analysis command enables you to detect if the part you drafted will be easily removed. This type of analysis is performed based on color ranges identifying zones on the analyzed element where the deviation from the draft direction at any point, corresponds to specified values.The draft analysis…

 General Guidelines for Bosses:   Draft  - 0.5 degrees on walls of boss   Thickness -  Typically 40%* of the nominal wall at the base.   Height to Diameter Ratio -  3:1   Radii - 0.25mm maximum radii.   "C" is where the doghouse contacts the backside…

Draft Analysis: The Draft Analysis command enables you to detect if the part you drafted will be easily removed. This type of analysis is performed based on color ranges identifying zones on the analyzed element where the deviation from the draft direction at any point, corresponds to specified values.The draft analysis…

Draft Analysis on A surface: The tooling axis is initially created according to the tooling direction.And draft analysis is carried out using that tooling axis and result is obtained with almost entire cad within the draft range.   The deviation shown in the picture is the minimum deviation and it is well within the…

Model 1: The parts for the assembly were separately created and then assembeled in the assembly workbench and the product file was attached to this challenge. Model 1 sketches: Part1:   Part2: Part3: Part4: Part5: Part Creation from the created sketch: Part1: Part2: Part3: Part4: Part5: Product: Model 2: The parts for…

Aim: To create a complete solid body of the inner door panel from the given Class A surfraces. Main substrate  ( Lower substrate ),Door arm rest , Map pocket and Bottle Holder are the A surfaces given to us and these are the parts that requires to be convertred into solid bodies and assemble them along with the attachment…

Benchmarking in the automobile industry Benchmarking involves a structured comparison between similar products, services or processes on some dimensions of performance. For example it can be used to compare the availability and delivery of features in a product and in this form often provides the basis of consumer tests…

Underbody coating: Vehicle undercoating is a process of rust proofing and protecting a vehicle from damage due to sand, gravel, road salts, and other grime, while helping reduce road noise. In areas of extreme climate changes, the lives of vehicles can be extended with proper undercoating. However, it is recommended that…

DOOR ARM REST: First the tooling axis created from the A surface as a reference. The orange axis is the side core axis and the white axis is the main tooling axis. Then the B surface is offseted for 2.5mm . Then the C surface is created using the boundaries from the A surface . Then the A surface is joined with the B surface…

Aim: To create a Outer and Inner Panel of a car Hood ( Bonnet) from given Clas A surface. Explanation: A car hood, also referred to as a bonnet in some other countries, is the hinged cover that rests over the engine of a front-engine vehicle. Its purpose is to provide access to the engine for repair and maintenance.…

Aim: To create a Fender from the given Class A surface with Flanges and Drip area which comes in a fender. Explanation:  A fender is the part of a car that protects and frames its wheels and keeps mud from splashing it. Most modern vehicles have fenders on their front wheels. When you get into a minor car accident,…

Aim: To validate the given fender design with the wheel arc and find out whether it is a successful model or a failure in real world. Wheel arc standard: Wheel arc standard is deiffrent in different countries and we in india follow the european standard for the wheel arc and it is shown below in the image. Wheel arc European…

Aim: To Design Bow roofs for the given Roof and reinforcements surface using the master section received from the styling team. Explanation: An automobile roof or car top is the portion of an automobile that sits above the passenger compartment, protecting the vehicle occupants from sun, wind, rain, and other external…

Objective: To develop an inner panel of Back door of a car from the given Class-A surface received from the styling team and create necessary emboss and reinforcements in the inner panel design. Explanation of a Back door: A back door of a car provides us with the access to the trunk of a car , and this back door houses…

Objective: To analyze the Hood design we have created by undergoing section modulus on the model. Section modulus: Section modulus is a geometric property for a given cross-section used in the design of beams or flexural members. Other geometric properties used in design include area for tension and shear, radius…
