To Calculate the concrete mix design for M35 Grade concrete with Fly ash Step 1              Grade designation                           : M35            Type of Cement   …

      AIM:              To prepare a residential plan fro G + 1 floor according to vaastu shastra and to calculate corresponding loads for componding loads for components house    PROCEDURE:     DETALID INTRODUCTION         The…

)Ans  Aim :   To create the geometers from P1 to P2 using all the coordinates system methods and P3 to P10 by any one coordinate system     To Draw the profile and the trusses using any coordinates system methods the dimensions are there for reference  INTRODUCTION:  Before going to the…

1.Create the templates as shown in figures.Take the size of the title block as per industry standards or tou can assume it as per the size of the paper Use text and attribtes wherever required After creating The title block you need to save it as a block with name: Custom1_ title block and Custom2_titleblock respectively…

1) Create the layouts of the Kitchen and provide hatches pattern as shown. Also, use blocks wherever required. Provide appropriate dimensions in the plan. Assume the size of doors, appliances and others as per the standards. AIM : To Create the kitchen layout and to also use proper dimension techniques to dimension…

Design and Draft a layout of a residential building  AIM: To Draw  1. Architectural Drawing (Floor plan, Elevations, and Sections) 2. Structural Drawing ( Column, Beam, Footing plan) Using Command: Line, offset, Retangle, Trim, Text, Move, Copy, Layers,Hatch, Dimension, Extend. Procedure:  First entran a…

1) Ans        Create a layout of the plan and Section A of the project in challages 7, using the template tutorial m Arch. dwt in a scal in figure aslo. used ATTEIDT command to edit the information in the title block use A1 size of the layout take a plot. AIM: To Create a layout of the plan and section…

1) Ans     AIM: Create a 3D Furniture element as shown in the Figure. Assume dimensions which are missing. INTRODUCTION: Draw the drawing in the 3D modeling and use the various 3D command and use the UCSto Make easy and fast to the drawing in realstic. PROCEDURE: Open to Autocad file and change units in Decimanls…

1) Ans  Create a 3D Isometric View of the building with plan and elevation given AIM : To Draw the 3D Isometric view of the building as show in the figure  Intriduction: A planview of wall and two evevation views one is of a window details and second is of floor level elevations are given and they are…

PROJECT : 2 Creating a 3D rendered model for a residential building in autocad. AIM: To Draw the 3D residental building and create the rendered view PROCEDURE: I am taking project -1 layout for creating 3D rendered view The command used in general for creating the elements are as folloows Line Rectangle copy move Erase …

1) ANS: a) This crack will be formed due to the flexural failure of a beam. The flexural strength, known as modulus of rupture, bend strength, or fracture strength, is a material property, defined as the stress in a material just before it yields in a flexure test. The flexural strength…

1. Differentiate Static analysis and Dynamic analysis with proper representing pictures ANS: Static analysis:   Static analysis of structures considers static loads acting on the structure such as dead, live loads which does not vary with time and are considered to be sudden. in static analysis siffness matrix alone is…

Question 1: A five storey structure with 5 translational DOF is shown here. Each storey has mass ‘m’. The eigenvalue problem has been solved and the 5 periods of vibration Tn and their corresponding mode shapes, φn has been derived. ANS: STEP - 1: The fundamental period of vibration (T1 = 2 seconds) and its associated…

1) Comment on the layout of the framing plan concerning earthquake resistance in the two horizontal directions X or Y (dots are columns, lines depict beams). Look into aspects of symmetry, redundancy and bi-directional stiffness and ductility. 1Ans: Symmetry: Moment resisting frames are uniformly distributed about both…

1)The building shown, 20 × 35 m in plan, has columns on a 5 × 5 m grid and shear walls (with dimensions shown in m, 250 mm in thickness) in three alternative arrangements, (a), (b), (c), all with the same total cross-sectional area of the shear walls. Compare the three alternatives, taking into account the…

1) Model a 25 storey building on ETABS with structural properties as specified below. Ground floor or plinth floor level can be taken at a height of 1.5 metres from the base. Each of the successive 25 storeys has a storey height of 3 metres. Structural Element Sizes  Beams : 300 × 400 mm  Columns : 800…

AIM:      The aim of this project is to compare the different story building for seismic forces as per the specification given. INTRODUCTION:                 The structural configuration of the building plays a major role in determining the overall response during…

Detail design of beams in Etabs 2018.The ETABS file for a G+4 building is provided. Run the analysis and design the RCC Moment ResistingFrame. The following challenge deals specifically with two continuous beams in the 1st floor.         1) 3 span continuous beam along grid A        2) 7 span continuous beam along grid…

Reinforcement detailing of columns in Etabs 2018. The ETABS file for a G+4 building is provided. Run the analysis and design the RCC Moment Resisting Frame. The following challenge deals specifically with two columns at the following grid intersections. 3A 3B Provide details of longitudinal reinforcement for the two columns,…

AIM:       To run the analysis and design the RCC shear walls shown in the ETABS model. INTRODUCTION:                            Reinforecement details of shear wall is provided acording to IS 13920:2016 STEP -1: open attachement…

1)ANS AIM:          The Isolated footing provided in week 11 challenge on Safe.          Analyze and design it to verify the size, depth and Steel provided as per calculations. PRODUCE: STEP-1: Frist open the CSI SAFE Software 20 Next select the New model Next model intialization …

AIM:         To create and Anaylse the given builidng in ETABS 2020, the strcutural model has to be prepared in accordance with IS1893 and as per IS 13920. To design the pile cap and pile reinforcement details. Tie beam connecting the pile caps, so sketch the column reinforcemet, to produce the…

1.ans

1)ANS:

1.1) ANS

1. Design a multi-story Residential Building located in Bangalore using STAAD Pro Connect Edition. The specification must be as follows: Building floors                 :  G + 6 +  R Plam Dimension               : B = 25m, L…

1. Design a warehouse building located in chennai using STAAD Pro connect Edition Specification must be as follows. Give data: Width =60M, Length = 50M, Eave Length = 9m, Bay spacing=6M, Soil type = medium, Safe Bearing capacity = 200KN/M^2 Roof Slope 1 in 12. 1. Prepare A Design Basic Report the project, 2. Create Structural…

1)
