Challenge 1 - The challenge is designed by selecting solenoid from electromnagnetic sensor which connected to battery through controlled switch. The electromagnetic sensor is read by translational motion sensor. The position port is connected to the scope to show whether it is moving. if the controlled switch is high,…

1. The simulation diagram is shown as follows Inputs to the chart Electric supply status (ESS) Time duration (T) Water supply status (W) Output Status of the machine. LED The ESS is verified with one at outside of the chart. So that the output of the logic is multiplied with time duration. The Time duration and W is given…

AIM: The aim of the project is to verify the change of velocity and rpm of the engine with changes in throttle input. Used blocks: The following blocks are used to validate the BAJA ATV with change of throttle input  1. Generic engine 2. Engine Sensor 3. CVT  4. gear 5. Vehicle body  Fig1. CVT with predefined…

The cargo mass is changed to 500 kgs.  With two drive cycles The EV runs 35.5 kms. The SoC is reached to 20%. so for utilising the battery, the extra drive cycle need to add  By observing the soc curve, it is concluded that the EV traveeled only 41.4 km. The SoC at 41.4 km is at 0%. 2. The capacity of battery…
