3D CAD MODEL :-  Sketch :-    Model Tree :-

Aim :- to perform drafting analysis on the given Fan component.  Given component :-                          Procedure:-  open the given CATPART and check for the gaps and boundaries of the component by using boundary option and selecting the whole component. any unwanted gaps in the model will be highlighted easily. the…

Aim :- To Create the Base Bracket Plastic component through the given Class-A surface. creating both class B & C surfaces and performing the draft analysis. Given Class -A surface :-  Procedure :-  check the class-a surface for any gaps or boundaries in the middle of the surfaces. check through boundaries…

Aim :- To Create the Switch Bezel Plastic component through the given Class-A surface, the tooling axis for the given Class-A Surface is created meeting the requirements of the draft angle and at the end perform the Draft analysis on the model.  Procedure :-  check for the Gaps in the middle of the given class-…

Aim :- Creation of a Door Arm rest with the reference of given Class-A and thickening it. also perform draft analysis to the given component. Procedure :-  the given component is a Class-A surface . check for the gaps in between the surfaces which are not desirable. select boundry option to easily visualise the surface…

Aim :-  Create the Coin Holder Plastic component through the given Class-A surface.  the tooling axis for the given Class-A Surface is created meeting the requirements of the draft angle and at the end perform the Draft analysis on the model. Thickness of the component to be 2.5 mm Procedure :- …

Aim :- To create Core & Cavity for th given switch bezel component, highlighting the Core and Cavity including the parting surface and parting lines. Procedure :-  The given model has a class-A surface. since the class-B and C surfaces are already created and the draft analysis is done on the component. insert…

Aim :- To create RIBS on the surface of the given Coin Holder component following the design rules for rib creation. Design Rules for Rib creation :-                              Procedure :-  The given component is a coin holder, ribs are…

Aim :- To Create the boss and Dog House for the Centre console coin holder considering the design rules mentioned. Given design rules :-                                     Procedure :-  The given component is a centre console…

Aim :-  Create the Base Bracket Plastic component through the given Class-A surface. To begin with, the tooling axis for the given Class-A Surface is created meeting the requirements of the draft angle and at the end perform the Draft analysis on the model.  Create the Heat Stakes and the locators considering…

Aim :- Master sections Development on a B-pillar surface. create class-B&C surfaces with reference, create features using the guidlines of  the master sections. perform draft analysis for the surfaces and features. Given :-  Class-A                           Master sections-                         Procedure :-  The given…

Aim :-  Development of a Door Trim panel.Creation of CAD model considering following inputs as like in OEM and tier1 companies a) Class A surface b) Nominal thickness : Refer master sections c) Attachment strategy :  Find a attachment strategy for the door panel complete work. Use Push pin with Dog house for…

Aim :- Benchmark with presently available cars in the market for the following case. Given case :-  Mr. D.S. Pughazhyendhii is a married man who lives in Bangalore which is a highly crowded city. His Family comprises five members including his wife, five-year-old boy, his father, and his mother. He visits…

UNDER BODY COATING - Underbody coating is a process where the under body of an automobile is treated with  chemical spray for the purpose of protection from rust and other causes such as Dust , moisture, rocks or stone chips getting thrown from the tyres which causes dents in the metal etc.. during monsoon conditions…

Aim :- Design Hood outer panel, inner panel and the necessary reinforcements by following the Master section mentioned with the design parameter . an assembly of Hood inner panel, outer panel, latch, hinge and the reinforcements Theory :-   a Hood  is the hinged cover that rests over the engine of a front-engine vehicle.…

Aim :-  Finding the section-modulus of the hood and improving by increasing the strength of the hood by alteration.  perfroming the case study. SectionModulus :- the geometry of thge given cross-section used in the design of beams etc.. also used in rdius of gyration for compression. the relationship depends…
