BENCHMARKING: Benchmarking in the automobile industry involves a structured comparison between similar products and services on some dimensions of Performance.  OBJECTIVE: Need to suggest the best car in the segment available between 8 to 10 lakhs segment. It should suit all of their requirements.   INPUTS GIVEN…

UNDERBODY COATING FOR CAR: The Car Body is made up of several Metals such as Iron, Steel, Aluminum, Copper etc. Rusting is the common term for corrosion of iron and its alloys. Corrosion is the reaction of Iron and Oxygen, as may present in Water or Air Moisture. Any Iron material when exposed to both oxygen and water…

DESIGNING A CAR HOOD – BIW INNER PANEL AND OUTER PANEL BY FOLLOWING EURO NCAP STANDARDS OBJECTIVE The main objective of this project is to design the Hood of a car that satisfies the manufacturing requirements, functional requirements, and as well as Euro NCAP standards. The Body in white (BIW) inner panel and outer…

OBJECTIVE:  The main objective of this project is to understand and learn the basic tools and advanced tools used in NX and calculation as well as section modulus and optimization of Car hood.   SECTIN MODULES: Section modulus is a geometric property for a given cross-section used in the design of beams…

AIM: To create a report on fender regulation and to calculation the wheel arc area and prove whether the car will get passed in the European standards or not. Fender: A fender is the part of a car, truck, motorcycle, or other vehicles that frames or covers a wheel well. Its main purpose is to prevent debris, rocks, mud,…

FENDER DESIGN OBJECTIVE : The main objective of this project is to design a fender using NX-CAD INTRODUCTION : The design of any product starts from a requirement. The design engineer sketches the product based on the requirement. Then the 2D sketch with the proper dimensions is converted into a 3D model using advanced…

WHAT IS ROOF IN AUTOMOBILES? An automobile roof or car top is the portion of an automobile that sits above the passenger compartment, protecting the vehicle occupants from sun, wind, rain, and other external elements.                                     Parts are in roof:-- OUTER ROOF  FRONT ROOF RAIL BOW ROOF 1 CENTER…

Aim:       To model a Backdoor of a car using NX CAD based on Engineering inputs, Design considerations that satisfy manufacturing requirements and functional requirements. Introduction:        A backdoor, also known as a 'tailgate', is a car's rearmost part. It is one of the BIW closure components. A door can be moved…

 Casing Design OBJECTIVE:-    To design a sheet metal casting part in UG NX with suitable commands to achieve the final product as per the given inputs.   INTRODUCTION:-    To create a new cad part we need to open NX and select New to create the new part file, its type and its location where…

BOX ASSEMBLY DESIGN OBJECTIVE:-    To design a sheet metal Box Assembly in UG NX with suitable commands to achieve the final product as per the given inputs.   INTRODUCTION:-    To create a new cad part we need to open NX and select New to create the new part file, its type and its location…

Odd-Shaped Enclosure:-   OBJECTIVE:- To design an odd-shaped Enclosure in NX cad as per the given dimensions.   Introduction:-  ENCLOSURE is a panel used to cover the body parts of a machine. Design approach:-   Description:-   Sketch: Representing the geometry in two-dimensional (Wireframe). Extrude:…

BRACKET:-   OBJECTIVE:- To design a Bracket in NX cad as per the given dimensions.   Introduction:- A Bracket is a sheet metal part used to hold a particular device/component in the machine or a system in a particular position. Brackets are in different shapes according to the requirements. Design approach:-…

BRACKET-II :-   OBJECTIVE:- To design a Bracket-II in NX cad as per the given dimensions.   Introduction:- A Bracket-II is a sheet metal part used to hold a particular device/component in the machine or a system in a particular position. Brackets are in different shapes according to the requirements. Design approach:-…

INPUT GIVEN : For both the exercise 2D diagram of individual parts and assembly is given as input.  STEPS FOLLOWED : Firstly, Individual parts have been created in the part (workbench all parts are saved in the same folder). EXERCISE - 1     EXERCISE - 2 Opened assembly workbench in Catia and called the…

INPUT GIVEN : CLASS A SURFACE (STYLING DATA) IS GIVEN. NEED TO CREATE PLASTIC PART WITH GIVEN STYLING DATA. USE CLOSED SURFACE COMMAND TO CREATE SOLID BODY.   CLASS A SURFACE : THERE WAS A SMALL ERROR IN SURFACES SO I USED THE TRIM COMMAND INSTEAD OF JOIN. JOINED USING TRIM COMMAND MADE A COPY OF THE GIVEN CLASS A…

INTRODUCTION: CLASS A SURFACE-STYING DATA GIVEN BY THE STYING TEAM. CLASS B SURFACE - ENGINEERING SURFACE CREATED WITH ENGG FEATURES BY PLASTIC PRODUCT DESIGN ENGINEER. CLASS C SURFACE -IT IS THE WALL SURFACE TO JOIN CLASS A AND B CREATED BY A PLASTIC PRODUCT DESIGN ENGINEER. INPUT GIVEN : CLASS A SURFACE…

BUMPER DESIGN AIM: TO CREATE A FRONT BUMPER WITH GIVEN STYLING DATA. FRONT BUMPER: ONE OF THE LARGEST AND COMPLEX EXTERIOR TRIM PART WHICH CARRIES MANY SYSTEM ON IT. MORE FREQUENTLY CHANGING PART IN FACELIFTS. FRONT BUMPER PLAY A VITAL ROLE IN THE FRONT LOOK OF A VEHICLE (AESTHETICALLY). INJECTION MOLDING PROCESS IS USED…

INPUT GIVEN:  CLASS A SURFACE  REFERENCE PIC OF THE FINAL PART WORK NEED TO DONE: SOLID PART USING CLOSED SURFACE COMMAND. NEED TO CREATE B SIDE FEATURE AS PER STANDARDS LEARNED(RIBS AND SCREW BOSSES). CLASS A SURFACE: THERE ARE NO GAPS IN GIVEN  CLASS A SURFACE.   TOOLING AXIS CREATION: SEEING ALL (X, Y, Z) AXIS VIEWS …

GIVEN INPUT: THICKNESS - 2.5mm   CONSTRUCT DOG AS PER DESIGN GUIDELINES.   REQUIRED OUTPUT: WE NEED TO CREATE A SOLID PART USING CLOSED SURFACE METHOD. ADD DOG HOUSE IN REQUIRED LOCATIONS.(REF IMAGE GIVEN)   CLASS A SURFACE: GIVEN STYLING SURFACE IS GOOD NOT HAVING GAPS INBETWEEN CONNECTION.   MAIN…

DOOR TRIM LOWER WITH ENGINEERING FEATURES: INPUT GIVEN: CLASS A (STYLING DATA) THICKNESS VALUE LOCATION FOR HEAT STAKE REQUIRED OUTPUT: SOLID PART(CLOSED SURFACE METHOD). ENGINEERING FEATURES AS SHOWN IN THE BELOW REFERENCE (HEAT STAKE, 2-WAY LOCATOR, 4-WAY LOCATOR). DRAFT ANALYSIS (CLASS A, FINAL COMPONENT). CLASS A SURFACE:…

A-PILLAR CHALLENGE: INPUT GIVEN:  2D DRAWING FOR DOG HOUSE. CLASS A SURFACE OF PRODUCT(A PILLAR). MASTER SECTION FOR REFERENCE. REQUIRED OUTPUT: CREATION OF SOLID PART USING CLOSED SURFACE FEATURE. CREATION OF A DOG HOUSE AS PER DESIGN GUIDELINES. REPORT GENERATION FOR PART. CLASS A SURFACE: THE GIVEN CLASS A IS VISUALLY…

FINAL PROJECT DOOR TRIM:     INPUT GIVEN: (DOOR PANEL) CLASS A SURFACES & MASTER SECTIONS FOR ALL PARTS IN ASSEMBLY FILE. IN THE MASTER SECTION, THE ATTACHMENT STRATEGY IS AVAILABLE. PUSHPIN CAD FILE. FOR LOWER SUBSTRATE AND DOOR PANEL ATTACHMENT USE PUSHPIN WITH DOG HOUSE. USE HEAT STAKES FOR PART-TO-PART…

OBJECTIVE: THE OBJECTIVE IS TO DESIGN AND ASSEMBLE THE PARTS IN ASSEMBLY WORKBENCH. THEN NEED TO CREATE A DRAWING FOR ASSEMBLY AND GD & NEED TO BE APPLIED.   BUTTERFLY VALVE: VALVES ARE USED TO CONTROL THE FLOW OF FLUID. BUTTERFLY VALVE IS USED HEAVY PIPELINES   PART MODELS: BODY PART:     SHAFT…
