Calculate the Concrete Mix Design for M35 grade concrete with fly ash  the mix design calculation of M35 Grade Concrete with Fly ash admixture and Poly Carboxylite type super plasticiser, as per Indian Standard Codebook IS10262(2009)  Guidelines for Concrete Mix Proportioning : Mix Design calculation procedure…

Sketch a G+1 floor residential plan, according to Vaastu Shastra, and list down the names of the structural drawings required to be provided to the site for construction. Also, assume the sizes of the structural elements (Column, Beam, Slab, etc.,) and accordingly calculate the individual corresponding loads from the members…

ANSWERS FOR ABOVE FIGURES : Step wise to draw the above figure : Select line tool and specify the first coordinate point 2,1 and click enter. we can use absolute coordinate system relative rectangular coordinate system and relative polar coordinate system. For the next point first we use absolute coordinate system. second…

By refering the given attachment question ,the answers are below .The answers are in image format and explation in text format .  Aim: To Draw C.S of load bearing wall over spread footing using autocad. Introduction: The spread footing is used shallow foundations.Over that we built load bearing wall. Procedure:…

Aim: To draw the given sketches in autocad. Introduction: autocad offers various tools like rotate,chamfer,fillet,move,offset etc to ease thr sketching process.  Command used : Line, circle, chamfer, fillet, mirror, trim, move, rotate, annotate. Procedure: Drawing 1: Procedure: 1.First in new drawing are setup…

1. Residence Plan: Sketch the layout of a residence as shown in the Figure 1. Consider all dimensions as reference to sketch the unit plan. Also the text in the layout are only for reference. Assume the missing dimensions. Also, refer the schedule for size of the doors. Procedure:   1. To sketch the layout of residence…

1. Create a column schedule as shown in the figure. Note: Create a column schedule with the help of lines. Also, insert text with the help of Dtext command or Single Line text. Hint: Use font name: romans.shx; Height: 8”, Justify: Left     A)A: 1.First open the autocad with imperical units tab. 2.The Enter…

  1. Draw the elevation and details of a wardrobe as shown in the Figure below. After sketching, you need to provide the dimensions and text with the use of layers. Use proper text styles and dimension methods to document it. Also, assume dimensions, wherever needed. Note: All dimensions are in mm.   A) 1.First…

1. Create the Plan and Sections as shown in the Figures. Use proper dimension techniques and dimension styles to document the project. Assume the sizes of the doors and windows as per construction standards. Refer to sections for stair details if required. A): 1.Open the new drawing file in autocad. 2.Set the units to…

Design and Draft a layout of a residential building with the following details: a. Plot Size: 60’x20’(18.3m x6m) b. Orientation- Facing East   c. Develop the following: 1. Architectural Drawing (Floor Plan, Elevations, and Sections) 2. Structural Drawing (Column, Bean, Footing Plan) ANS: 1. First we have…

1. Create the templates as shown in Figures. Take the size of the title block as per industry standards or you can assume it as per the size of the paper. Use text and attributes wherever required. After creating the title block you need to save it as a block with names: Custom1_titleblock and Custom2_titleblock, respectively.…

1.Create the layouts of the Kitchen and provide hatches pattern as shown. Also, use blocks wherever required. Provide appropriate dimensions in the plan. Assume the size of doors, appliances and others as per the standards. ANS: AIM: To Create the layouts of the Kitchen and provide hatches pattern as shown. Also, use blocks…

Your Answers 1. Create a layout of the Plan and Section A of the project in Challenges 7, using the template Tutorial-mArch.dwt in a scale as given in the Figure. Use the MV command to create the viewport of the size as shown in Figure. Also, use ATTEDIT command to edit the information in the title block. Use A1 size for…

1. Create a 3D Furniture element as shown in the Figure. Assume dimensions which are missing. ANS:   Aim: To Create a 3D furniture element given. Introduction:To create 3D elements we have use 3D modeling.3D modeling is used to create the elements in all 3 dimensions. Procedure: 1.To create the 3D elements first we…

1. Create a 3D Isometric View of the building with plan and elevation given. ANS:     AIM: To Create a 3D Isometric View of the building with plan and elevation given. Introduction: In AutoCAD the 3D models are drawn with 3D modelling.The 3d model shows the x,y and z axis of the through this we can visualise…

Procedure:   1.First we have to open AutoCAD software.   2.Then we have to set the AutoCAD from drafting and designing to 3D modelling.   3.Then we have to set the units to engineering units.   4.Then we have to draw the plan and elevation on the xy plane.   5.Then set the ucs to 3D that shows…
