MODELING OF AMERIACAN CHOPPER USING SOLIDWORKS   OBJECTIVES: Main objectives of this project is to create model of different parts of AMERICAN CHOPPER using SOLIDWORKS To assemble the different parts modeled for the AMERICAN CHOPPER To create photo-realastic view of the American Chopper by rendering the model using…

1.RADAR MAST         2.YACHT ASSEMBLY   3.REPORT MODELING OF YACHT USING SOLIDWORKS OBJECTIVES: Main objective of this project is to create model of different parts of YACHT using SOLIDWORKS. To assemble the different parts modeled for the YACHT. To create render model using SOLIDWORKS Photo-VIEW…

  SHEET METAL CASING USING NX Objective: Main objective of  this project is to create sheet metal casing using NX. Design Methodology:     FEATURES DISCRIPTION: TAB: Tab is feature is used to convert 2D sketch in to sheet of required thickness. NORMAL CUT: Normal cut is another cool feature which helps…

SHEET METAL DESIGN OF BOX ASSEMBLY USING NX Objective: Main objective of  this project is to create sheet metal design of BOX ASSEMBLY using NX. Design Methodology:     FEATURES DISCRIPTION: TAB: Tab is feature is used to convert 2D sketch in to sheet of required thickness. NORMAL CUT: Normal cut is another…

  CREATING SHEETMETAL FROM SOLIDBODIES USING NX Objective: Main objective of  this project is to convert solid bodies in to sheet metal form using NX. Design Methodology:   FEATURES DISCRIPTION: EXTRUDE: This feature used to convert 2D sketch into 3D model. SHEET METAL FROM SOLID: This feature helps to convert…

CREATING BRACKET FROM THE 2D DRAWING USING NX Objective: Main objective of  this project is to create bracket from the 2D drawing using NX. Design Methodology: COUNTER FLANGE: Creates a base feature by extruding a sketch along a vector, or adds material by sweeping a sketch along an edge or chain of edges. NORMAL…

CREATING METAL BRACKET FROM THE 2D DRAWING USING NX Objective: Main objective of  this project is to create metal bracket from the 2D drawing using NX. Design Methodology: FEATURES DISCRIPTION: NORMAL CUTOUT: CUTS THE MODEL PERPENDICULAR TO THE SKETCH ADVANCE FLANGE: Adds flange along an edge using a bend angle or…

KIA SONET(RATING: 3.5/5) PRICE ₹ 8.19 Lakh onwards MILEAGE 18.2 to 24.1 kmpl ENGINE 998 to 1493 cc TRANSMISSION Manual, Clutchless Manual, Automatic (Torque Converter) & Automatic (Dual Clutch) FUEL TYPE Petrol & Diesel SEATING CAPACITY 5 Seater         Why would I buy it? iMT…

Underbody Coating In Indian road conditions, a cars underbody is most prone to corrosion. Underbody coating provides long term protection from corrosion to car’s underbody. It also protects parts like internal body panels, frame rails and other inner cavities that are not physically accessible but are prone to corrosion.…

CAR HOOD DESIGN AIM: To design a car hood and understand the mechanism behind the design of hood, the development of hood &its safety feature as per the design consideration. The following tasks are performed: Design outer panel with hem Develop the inner panel Develop all necessary reinforcement Mirror and position hinge…

Purpose: To design the Drip Area, Sillmount area, bumper mount region and A-pillar mount Region. THEORY: FENDER : Fender covers a wheel, traditionally to prevent water and mud spray, but now also for aerodynamic purposes. Bumper protects the body from small impacts to the front or rear of the vehicle Sticky materials,…

SECTION MODULUS OF AN HOOD Section modulus is a direct measure of strength of any sectional area of an object about an reference axis (neutral axis). Strength is nothing but, capable of supporting greater loads, so higher the strength it has a high capable of supporting greater • This strength can measured directly…

Objective: For the given Car Roof styling, design and develop the essential flanges and reinforcements, namely the Ditch Area, Front Roof Rail, Rear Roof Rail, Centre Roof Rail and Bow-Roofs. Do a curvature study on the roof and perform calculations for Heat Distortion and Snow load criterion to determine and justify the…

AlM: Using the provided styling surface to come up with a back door design and using appropriate design methodologies and make the necessary reinforcements and embosses What is a back door? A door s hinged part which is used for entry and exit of the vehicles. Back doors are one of the type doors of the vehicle which are…

Aim: To perfrom Draft analysis on a Fan Cover. Theory: Draft Analysis is performed to check the manufacturability of the product.In Draft Analysis, the Class C surface i.e.side walls are checked for draft. A minimum if 3 degrees draft is expected on the component to make it manufacturable without any damage to the product.…

AIM: Create the Base Bracket Plastic component through the given Class-A surface. And perform the Draft analysis on the model. OBJECTIVES: To model a base bracket and perform draft analysis on the model. THEORY: Draft Analysis: Draft analysis helps to detect if your drafted part is easily removable from the mold (in case…

Objective: To design switch bezel as per automotive OEM Standard. Create B Class and C Class and tooling axis. • Converting close surface into the solid inside part workbench and provide the thickness of 2.5mm. Performing draft analysis to verify the creation of the Tooling axis and C Class surface. Software: CATIA…
