Calculate the Concrete Mix Design for M35 grade concrete with fly ash. Aim: Calculation of the Concrete Mix Design for M35 grade Concrete with fly ash. Formula: f’ck= fck +1.65 s                  f’ck = target mean strength…

Aim: Sketching the G+1 floor residential plan satisfying the vastu shastra and calculating the load acting on the building with giving the information of the required drawings. Also, assume the sizes of the structural elements (Column, Beam, Slab, etc.,) and accordingly calculate the individual corresponding loads from…

Aim: To Creating the geometries from P1 to P2 using all the coordinates system methods. By using the Line tool to create the geometries, and circle tool while requiring. Procedure in detail: P1 :   P2:   P4: P5: P7: P8: P9 P10 Figures Related to civil: Profile Wood:   Queen Post Truss:   Mono Pitch:…

Aim: To create the  MODEL OF C1, C2, C3, C4, C5 and C6 IN Autocad software and explaining the procedure in report format  shown as a given below. INTRODUCTION: Open the Autocad software from destop or go to the start>all program>Autocad. Click New to open a new drawing. Type L and enter this is a command…

Aim: To draw the given Architectural drawing of a residential building: Plan of a residential building. Elevation of a residential building. Section of a residential building. Structural drawing: Column plan layout of the building. Footing plan layout of the building. Beam plan layout of the building. Commands used:…

Q1. Aim: Create the templates by Using text and attributes wherever required. After creating the title block saveing it as a block with names: Custom1_titleblock and Custom2_titleblock, respectively. Result: i) Custom1_titleblock- ii) Custom2_titleblock- The attributes created are: After creating it as a block we…

Q1. Aim: Creating the layouts of the Kitchen. Result: Q2. Aim: Creating the elevation of the plan created in the Challenges 7. Result: Q3. Aim: Creating the section view of an industrial building. Result:

Q1. Aim:  To Create a layout of the plan and section A of the project in challenges 7. Result: Q2: Aim: To create layout of the kitchen drawn in challenge 9 . Use A4 size page for the layout  and take a plot. Result: Q3: Aim: Create a layout of the section created in Challenges 9.Use scale as mentioned in the Figure. Use…

AIM: To create 3D model and view of: Furniture element Isolated footing AASTHO type girder Drop column with panel A wall DRAWING OF 3D FURNITURE ELEMENT: 1). Aim:  To create a 3D model of the furniture element. RESULT: 2). 3D MODEL OF ISOLATED FOOTING: Aim: To create a 3d model of isolated footing RESULT:…

Q1. Aim: To draw the 3D Isometric View of the building as shown in the figure   Q2. Aim: To draw the 3D Building Façade as given in the plan and elevation. Detailed window: Q3:  Aim: To draw the 3D view of  a stair with railing as shown in the plan and elevation. Side Elevation:  …

PROJECT AIM - Creating a 3D rendered model for a Residential Building in AutoCad. INTRODUCTION- COMMANDS USED FOR DRAWING THE 3D RENDERED VIEW OF BUILDING ARE -  Extrude -   Sweep -   Union  -   Subtract  -   Intersect  -   Revolve…

Q1.) Based on the project saved from Week 3, proceed from the First Floor Level. Model a Ceiling from the architecture tab above the walls at the first-floor level Answer:     AIM:- To model a Ceiling from the architecture tab above the walls at the first-floor level. Result:        …

Q1) Select the type of structure you want to build from one of the three below:        a. Multi-Unit Residential Apartment        b. Office Buildings        c. School Answer: Aim: To Select the type of structure need to build from one of the three below: …

Q1.) Using Dynamo create a set of sinusoidal points and create a curve and create a surface out of the curve. Aim: To create a set of sinusoidal points, a curve and a surface out of the curve using dynamo. Procedure: Initially, open the architecture template of Revit software and go to manage tab. In manage tab select…

Q1.  Use the Architecture/ Structure Project file developed by you in Week 6 to 8. Export the Revit architecture and structure model to Navisworks Cache file following the export settings discussed in class Answer: Aim: Using the Architecture/ Structure Project file developed and exporting the Revit architecture…

Question 1: What is the mode of failure or damage of the beams in the figure above? Would you characterize the case as damage or as a failure? Are the damages repairable? Elaborate Answer: a)  Crack is formed due to flexural failure in beams. As we can see that damage is caused more to the beam then column. Damage is caused…

Q1. Write the steps involved to upload a .std file through web mail?     2. Name the different materials that can be designed using STAAD Pro.     3. Is it possible to capture images in STAAD Pro? If yes how?     4. Name the three ways by which you can create a model.     5. Write…

AIM: - To explain the answer for each and every question from 1.1.1 to 3.1.5.  INTRODUCTION: -  In this section of question from 1.1.1 to 3.1.5, I used staad.pro software to answer these question. Besides this, I have used some reference from recorded video session of skill-lync. PROCEDURE: - Here first…

Q1. 1. State the primary load cases to be considered for design. ANS: State the primary load cases to be considered for design. Ans: Dead Load ,Live Load ,Snow Load, Seismic Load, Wind Load   Q1.2. What is One – Way slab? ANS: Ans: The one-way slab is a slab, which is supported by parallel walls or…

Aim:- To design a multi-storey Residential Building located in Bangalore using STAAD Pro Connect Edition Procedure:-  Unit weight of the materials SNO Name of material Unit weight 1 Reinforced Cement Concrete 25">2525 kN/m3">kN/m3kN/m3 2 Plain Cement Concrete 24">2424 kN/m3">kN/m3kN/m3 3…

1. Design a Warehouse Building located in Chennai using STAAD Pro Connect Edition. The specification must be as follows:      Width  30m Length 50m Eave Height 9m Bay spacing 6m Soil type Medium Safe Bearing Capacity 200 kN/m2 Roof slope 1 in 12              …

Q1. Differentiate Static analysis and Dynamic analysis with proper representing pictures  ANSWER: STATIC ANALYSIS:   The main difference between static and dynamic analysis is TIME! If the load is applied so slowly, that inertia effects won’t play a role, all you need is static analysis. Static analysis time invariant…

Q1. Summarize the user interface in TSD with the for the following items: -  Project Workspace – How to access and usage  Scene Content – Demonstrate the use of scene content Create two scene views Loading drop list- How to access Properties windows – how to access and usage Answer: 1. Project…

Q1. Create column properties for different types of pedestal members and model in the grids created as per the assignment 1 ANSWER: AIM: To create column properties for different types of pedestal members and model in the grids created as per the assignment 1 Introduction: The pedestal is the block of concrete that…

Q1 Answer: Investigation of the Framing Plan for Symmetry in the X-DirectionUpon dividing the plan vertically down the center, the two halves appear as mirror images of each other. Therefore, we can conclude that the framing plan exhibits symmetry in the X-direction.Investigation of the Framing Plan for…

Question 1: The building shown, 20 × 35 m in plan, has columns on a 5 × 5 m grid and shear walls (with dimensions shown in m, 250 mm in thickness) in three alternative arrangements, (a), (b), (c), all with the same total cross-sectional area of the shear walls. Compare the three alternatives, taking into account the restraint…
