AIM:To Assemble and apply GD&T to the butterfly valve assembly drawing. OBJECTIVE: To design of Butterfly Valve in appropriate dimension with the application of GD&T  To assemble all the parts of the butterfly valve by assigning suitable constraints. To understand the concept of geometric tolerance and dimensioning.  INTRODUCTION:…

AIM:To develop the Car Door Trim Panel of a car using CATIA V5 by Using the Class A surface and Master sections as input.Create the Solid body and Design the engineering features like Heatsteak,Locators,Flanges,Doghouse and attach the push pin.  Components in Door Trim panel, Arm Rest Upper Map Lower Map Pocket Lower…

AIM:To create the A-Pillar Plastic component from the given Class A Surface and Using the Master Section Create Doghouse following all the design rules. INTRODUCTION: A-PILLAR A-Pillers are the structural supports for the car's roof and window areas.A-Pillar is located on either side of your…

AIM:To create a solid body of 'Door Trim Lower' with the help of the closed surface method by using the 'Generative shape design' workbench. Performing the 'Draft Analysis' on the solid part body of the Door trim.Create the Heat Stakes and the locators considering the design rules.   OBJECTIVE: To create a tooling…

AIM:To create the Door Trim Plastic Component from the given Class A Surface & then create two dog houses as attachment features for it while following the given Design Guidelines. OBJECTIVE: To create a tooling direction. To perform draft analysis for given  Class A-Surface . To design the B-Surface and C-Surface using…

AIM:To create Rib and Screw Boss to the given Door Handle.From the Class A create the tooling axis,Class B and perform the draft analysis on the model. OBJECTIVE: To create a tooling direction. To perform draft analysis for given  Class A-Surface . To design the B-Surface and C-Surface using the given Class-A…

AIM:Create the Bumper Plastic component through the given Class-A Surface. INTRODUCTION: Create the Bumper Plastic component through the given Class-A surface. To begin with, the tooling axis for the given Class-A Surface should be created meeting the requirements of the draft angle and at the end perform the Draft analysis…

AIM:Create the Switch Bezel Plastic component through the given Class-A surface and perform the draft analysis. OBJECTIVE: Ensure Proper Tree Structure. Geometrical sets should have a proper name based on the sketches present inside them. All the sketches should be created under the Geometrical set.  Use the Close…

AIM:Create the Base Bracket Plastic component through the given Class-A surface and A detailed report should be done explaining the draft analysis and the tooling axis creation. INTRODUCTION: The main objective of this challenge is to create the Base Bracket Plastic component through the above-given Class-A surface,…

AIM:To create Assemblies with provided 2D diagram DRAWING 1 QUICK RETURN MECHANISM            SKETCHES                                                      …

CAR BACK DOOR DESIGN AIM: To design back door of car using given outer class 'A' surface. INTRODUCTION: A door which is located at the rear side of a car which gives access for the boot space to store luggage, spare wheel etc.These doors can be operated manually or electric powered. In most of the luxury cars door is electrically…

AIM: To design a car roof with all the components using the given master section and Calculating Heat distortion and Snow load on the roof,Section inertia. OBJECTIVE: To design the automotive roof based on the given styling surface and to analyze the prepared model to check the manufacturability and the feasibility…

AIM:The main objective of this challenge is to design a front fender of a car using the given master section and explain about fender and its design parameters.   INTRODUCTION: Fender is American English  term for the part of an automobile, motorcycle or other vehicle body that frames a wheel well…

WHEEL ARCH CHALLENGEAIM:To check whether the given design passes the European standards or not.          FENDER:Fender is a part of an automobile, motorcycle or other vehicle body that frames a wheel well (the fender underside). Its primary purpose is to prevent sand, mud, rocks, liquids and…

AIM:To find the section modulus of the hood and optimisation to improve the overall section modulus and explanation about section modulus   SECTION MODULUS: Section Modulus is a geometric property used to calculate the bending stresses in a structural member. It is defined as the ratio of moment of inertia of a section…

AIM:  To design car hood in NX CAD using given master section and analysis it's components. INTRODUCTION: A car hood is the metal part that covers the engine of an automobile. The term car hood is a North American term, used primarily in America and Canada. Hood comes from the Old English…

Case Study:To expain about Benchmarking and finding a good car for Mr.D.S.Pughazhyendhii by  comparing the  Cars. BENCHMARKING: Benchmarking is a process of measuring the performance of a company’s products, services, or processes against those of another business considered to be the best in the industry,…

INTRODUCTION: The underbelly of every vehicle needs proper care and protection due to various climate changes.Underbody coating helps protect your vehicle against rust and corrosion. In indian road condition a car's underbody is most prone to corrosion.Under body coating provides long term protection from corrosion to…
