what is bench-marking It is an comparison between two objectes, services, process, etc. and also to identify the problem for improvement  it is called bench-marking    These are the cars available acording to Mr. D.S. Pughazhyendhii's demand Hyundai venue (suv) PRICE (lakhs) 7.53L - 12.72L CITY…

UNDERSEAL Underseal is also called as under-body coating is a dence cladding often based on rubber material it is coated by sprayed or painted under clean surface of the vehicle, which prevents damage caused from impact damage of small stones and other substance chip off the paint that leades to start rusting under the…

HOOD DESIGN AIM: To design Inner Panel with reference to hood outer panel and assemble hinge, latch and striker with reference to master selection and provide mastic points and its reinforcement. INTRODUCTION In the car bonnet or hood are the main components which is located in front portion, it is used to access to the…

REPORT The tooling axis is created by following the steps  check the possibility of tooling axis along the axis XYZ if not go for bisecting lines The bisecting line is created in the point on the surface and parallel lines on the class A surface draft analysis  class C is created with the draft angle of 3 degrees…

    REPORT RIBS  The height of the ribs Should be less than or equal to 5mm*T. "T refers to the thickness of the component", and the thickness of the ribs is 0.5 times the thickness (T). The minimum draft angle of the ribs is 0.5 degrees. So the draft angle is calculated by 0.5 degrees*T times thickness,…

  REPORT DRAFT ANALYSIS For this type of engineering feature, the side core tooling axis is provided, and the inside draft is given 0.6 degrees for the dog house. The wall thickness has given a 2:3 ratio example if the component thickness is 3mm, the wall thickness of the dog house is 2mm. and a slot is given to the…

   REPORT DRAFT ANALYSIS Heat stakes and locators are created according to the design rules. ribs are provided to support the strength of the heat stakes. tooling axis is created along the y axis The tooling axis is created by following the steps  check the possibility of tooling axis along the…

REPORT DRAFT ANALYSIS The tooling axis is created along the Y axis and also improved class A surface is created but after creating B side features and taking draft analysis deviation happened in the dog house so I have altered the tooling axis with a bisecting method with reference to the dog house, 3 degrees draft is…

Section Modulus Section modulus is the ratio of bending to the farthest fiber from the neutral axis, or it is the measure of the strength of the beam. The ratio of the Area Moment of Inertia to the Distance from the Neutral Axis to the Point where the Bending Normal Stress is determined. It is a geometric property used…

REPORT SA is a vertical line from the axis of the wheel, SB is on the left, and SC in the right at 30 and 50 degrees respectively which are done according to the Japanese standards and, if we add a 150mm vertical line from the horizontal reference line on the axis of the wheel to the point touch the curvature of the fender,…

REPORT   FENDER DESIGN A fender is a metal or plastic enclosure over the wheels of an automobile and its primary purpose is to prevent sand, mud, rocks, liquids, and other road sprays from being thrown into the air by the rotating tire. Fenders are typically rigid and can be damaged by contact with the road surface.…

AIM: To create an ASSEMBLY by developing the essential flanges for the outer roof and creating the front roof rail, rear roof rail, center roof rail with reinforcements, and bow roof with the Given Roof styling.   OBJECTIVE: To design a roof and its internal components. To Provide appropriate dimensions and check…

BACK DOOR   Aim: To design a car back door inner panel with a proper draft angle for manufacturability and its necessary reinforcements.   Introduction: The car door is considered a door when it has a hinge. The back door is on the back side of the door it is also called the trunk, the boot of a car, the cargo…

  1)Download the following cad data & define it as Electrical support using the Electrical Part Design Workbench. Define all the necessary properties. P clamp   2) Download the following Back shell cad data & define it as an Electrical back shell using the Electrical Part Design Workbench. Define all…

AIM:   To define Electrical properties of the given components.   OBJECTIVE: To download the above CAD data of the parts. To define the Electrical properties. To create catalogues.   CATALOGUE DOCUMENT: First a new 'catalogue document' is created and then add family in ordered to add the group of components.…

Define the mechanical components electrically and prepare the catalogue for the same   Check the bundle is continous and the annotations are added for all the components in the assembly   prepare the interconnection for harness A and B
