Aim:           To write code to solve an otto cycle and make plots for it. with PV diagram and for the thermal efficiency of the                            engine Theory:               …

Aim:           To Write a program in Python that will simulate the pendulum motion, just like the one shown in the start of this                     challenge. Theory:                  …

Popt and pcov fuctions actually used for:         popt, pcov = curve_fit(func), The function returns an array popt and pcot with the optimal parameters obtained using a non-linear least squares. np.array(temperature):       The diagonals provide the variance of the parameter estimate.…

Aim:   Data visualizer Your script should take column numbers as the input and plot the respective columns as separate images. Each file should be saved by the name of the column. The plot labels should be extracted from the file. If, I request for a plot between column 1 (crank angle) and column 8(volume), then the…

AIM: To create the Base Bracket Plastic component through the given Class-A surface. To begin with, the tooling axis for the          given Class-A Surface should be created meeting the requirements of the draft angle and at the end perform the Draft           analysis…

AIM: To create the Switch Bezel Plastic component through the given Class-A surface. To begin with, the tooling axis for the          given Class-A Surface should be created meeting the requirements of the draft angle and at the end perform the Draft          analysis…

AIM: To create the Coin Holder Plastic component through the given Class-A surface. To begin with, the tooling axis for the          given Class-A Surface should be created meeting the requirements of the draft angle and at the end perform the Draft          analysis on the model.           Take the Thickness of the component…

AIM: To create the Bumper Plastic component through the given Class-A surface. To begin with, the tooling axis for the given         Class-A Surface should be created meeting the requirements of the draft angle and at the end perform the Draft analysis          on the model.…

AIM: To create the Core and cavity blocks for the switch bezel designed in the earlier challenge.   Objective : To design core and cavity for switch bezel with 3 mm thickness Performing draft analysis to verify the creation of the Tooling axis and C Class surface. Draft Analysis: The Draft Analysis…

AIM: To create the rib for the Drill Handle considering the design rules mentioned in the video.      Create the Screw boss for the Drill Handle considering the design rules mentioned in the video.  General Guidelines for Bosses:   Draft  - 0.5 degrees on the walls of boss   Thickness -  Typically 40%* of the nominal wall…

AIM: To create the Dog House for the Door Trim considering the design rules mentioned in the video. Consider the thickness of the part to                  be 2.5 mm.           "C" is where the doghouse contacts the backside of the…

AIM: To create the Door Trim Lower Plastic component through the given Class-A surface. To begin with, the tooling axis for the given          Class-A Surface should be created meeting the requirements of the draft angle and at the end perform the Draft analysis on the model.   …

OBJECTIVES: To create the class B and class C surfaces from the given class A surface. To form a solid geometry by combining all the surfaces. To create a dog house for the solid part whilst following the design rules. To perform draft analysis on the class A surface and the solid part model.   The structure…

ASSEMBLY WORK BENCH Objective: To create assembly as per the given details. Aim:  1-create the parts and assemble the Quick reaction motion.   GIVEN 2D- SKETCHES   Link for Model drawing 1 Link for Model Drawing 2     MODEL-1:     BODY-1:     BODY-2:    …

AIM: To create a door interior part from the inputs of class A surface along with master section by following the design rules followed in tier 1 and OEM industries in catia v5 SOFTWARE USED: CATIA V5 OBJECTIVES: Create a sketch by using Positioned sketch All the should be sketches should be Iso-Constrained Ensured Proper…

AIM: DETAILED REPORT ON BENCHMARKING          To prepare a report let us know about what is Bench-marking , Compare at least 4 Vehicles and Provide a Preoper conclusion for the report,                      suggesting a suitable vehicle among…

What is Under-body coating? Underbody coating is a thick cladding (typically made of rubber) that is placed uniformly to the car’s underside. When the automobile is fresh off the lot and spotless, it is usually sprayed or painted on. But it’s acceptable if you apply the undercoating after a couple of years.…

Aim: To design car hood in NX using given master section and provided design parameters.       Hood and it’s components: Hood:–Car hood is a hinged cover that rests over the engine in a front-engine car. A latch is provided under the hood in order to prevent accidental opening during driving. Purpose of hood is to provide…

SECTION MODULUS OF THE HOOD Objective: To find the section modulus of the hood and optimisation to improve the overall section modulus. Section Modulus: The section modulus (S) is geometric property of the cross section used for designing beams and flexural members. It does not represent anything physically. Formula of…

Wheel Arc area Calculation – Fender DesignAim: To determine the Wheel arc area and i have to check whether the given fender design complies with the European standards or not. Inputs: Model of Front fender and wheel,European standards for Wheel Arc area.     Checkpoints: For the arc area…

FENDER DESIGN AIM: To design a front fender of a car by following the given master section as per the design considerations of OEM.   FENDER:  It is a plastic, metal, or rubber curved panel over the wheels on the side of a car, extending from the front bumper of the car to the door. The…

Objective: The main objective of this project is to develop the car roof design and its reinforcements from the given styling surface. And to prepare a detailed report about the engineering standards for roof design, its design procedure, Draft analysis and manufacturing techniques. Introduction: An automobile roof or…

AIM: To design the outer upper and lower panel, inner panel with the necessary reinforcements by following the Master section with the design parameter for the given class A surface. Backdoor File (.prt) Backdoor File (.igs)   INTRODUCTION: A door is a hinged part which is used for entry and exit of the vehicles.…

AIM: Download following connectors & Connector clip cad data from given link & define it as Electrical Connector using Electrical Part design Workbench. Define all the necessary properties to Connectors & Clip.   Deutsch DT06 – 08SA ( https://www.te.com/usa-en/product-DT06-08SA.html) Tyco 174357-2…

Q1. Download following cad data & define it as Electrical support using Electrical Part design Workbench. Define all the                       necessary properties. P clamp       Process: Create two points one as entry and another as exit point.…

Aim: 1) To Route the following harness layout in the Electrical workbench. 2) Add protective covering on all branches connected to DT06-2S & DT06-4S connectors. Given Data: CAD data of the following Connectors: DT06-4S DT06-6S DT06-2S DT06-08SA Connectors Layout Design: 1. Download connector 3D data…

WIRING HARNESS DESIGN IN CATIA V5 - 3D MODELING WEEK 5 & 6 CHALLENGE AIM- Route two electrical harnesses as per the given layout and interconnect them as a single harness assembly and then check for bundle continuity, bundle warnings, and then give annotations to the final harness assembly. OBJECTIVE- The objective…

Aim: To flatten the wiring harness and the draft the wiring harness assembly.   To place the flattened view on a drawing sheet. To ensure bundles with protective coverings has different visuals on drawing view   Harness assembly:   Step - 1: Create a product file and navigate to the Electrical…

WIRING HARNESS DESIGN PROJECT 1 AIM:  To design and develop the Wiring harness on Given V6 Engine and Prepare flatten view drawing in CATIA V5. Application of all Packaging rules, Industry best practices studied in this course shall be demonstrated in design. GIVEN ENGINE DATA FILE: Engine cad data to be downloaded…

Aim: To route the wiring harness on the given tailgate assembly and prepare the flatten view drawing in CATIA V5.  Given:                     DESIGN CRITERIA AND PACKAGING ASSUMPTIONS: Wiring harness routing shall provide ease in manufacturing, accessibility, easy removal, and easy maintenance of attached equipment and…
