Aim: To write a program that solves the following ODE which represents the equation of motion of a simple pendulum with damping. ODE:   CODE: clear all close all clc %Inputs for pendulum b=0.09; %Damping Coefficient of pendulum. m=0.1; %Mass of bob. g=9.81; %Accelaration due to gravity. L=1; %Length of string…

AIM: To write a code in MATLAB to optimise the stalagmite function and find the global maxima of the function.   OBJECTIVES:  1) Clearly expalin the concept of genetic algorithm in your own words and also explain the syntax for ga in MATLAB in your report. 2) Plot graphs for…

AIM: To write a code in Matlab to the parse the NASA thermodynamic data file and then calculate the thermodynamic properties of varoius gas species. OBEJECTIVE: 1) To write a function that extracts the 14 co-efficients and calculates the enthalpy, entropy and specific heats for all the species in NASA thermodynamic…

AIM: Write a code to calculate the state points of the Rankine Cycle (any type of your choice) based on user inputs.  OBJECTIVE: Plot the corresponding T-s and h-s plots for the given set of inputs. Title and axes labels are a must, while legends could be used if necessary. Attach a report explaining the working…

AIM: Create a MATLAB program for the Simulation of Whitworth Quick Return Mechanism.   OBJECTIVE: Plot a graph between crank angle and velocity of ram. Plot a graph between crank angle and acceleration of ram.   THEORY:  The Whitworth quick return mechanism converts rotary motion into reciprocating motion,…

AIM: Create a MATLAB program for the Simulation of Whitworth Qucik Return Mechanism.   LINK TO ACCESS THE PROJECT - WHITWORTH QUICK RETURN MECHANISM:   https://skill-lync.com/projects/whitworth-quick-return-mechanism   ERRORS FACED WHILE CODING:   2) Conversion from double to struct is not possible…

AIM: Create the tooling axis for the given Fan cover model meeting the requirements of the draft angle and perform the Draft analysis on the model. REPORT ON DRAFT ANALYSIS:  STEP 1: 1st to check the connectivity of the Class A surafce. Ensure that there is no gap between the component, using join command. We can visually…

AIM: Create the Base Bracket Plastic component through the given Class-A surface. To begin with, the tooling axis for the given Class-A Surface should be created meeting the requirements of the draft angle and at the end perform the Draft analysis on the model.  REPORT ON DRAFT ANALYSIS: Given Class A Surface:…

AIM: Create the Switch Bezel Plastic component through the given Class-A surface. To begin with, the tooling axis for the given Class-A Surface should be created meeting the requirements of the draft angle and at the end perform the Draft analysis on the model.    REPORT ON DRAFT ANALYSIS: Given Class A…

AIM: Creation of Door Arm rest and add thickness to it:

AIM: Create the Coin Holder Plastic component through the given Class-A surface. To begin with, the tooling axis for the given Class-A Surface should be created meeting the requirements of the draft angle and at the end perform the Draft analysis on the model.  REPORT ON DRAFT ANALYSIS: Given Class A Surface:…

AIM: Create the Core and cavity blocks for the switch bezel designed in the earlier challenge.  REPORT ON DRAFT ANALYSIS: Given Class A Surface: STEP 1: Check the connectivity of the Class A  Surface Ensure that there is no gap between the component, using join command. We can visually check it or by clicking…

AIM: Create the rib for the Centre console coin holder considering the design rules mentioned in the video. REPORT ON DRAFT ANALYSIS: Given Class A Surface: STEP 1: Check the connectivity of the Class A  Surface Ensure that there is no gap between the component, using join command. We can visually check it or…

AIM: Create the boss and Dog House for the Centre console coin holder considering the design rules. REPORT ON DRAFT ANALYSIS: Given Class A Surface:   STEP 1: Check the connectivity of the Class A  Surface Ensure that there is no gap between the component, using join command. We can visually check it or…

AIM: Create the Heat Stakes and the locators considering the design rules for the door applique.  REPORT ON DRAFT ANALYSIS: Given Class A Surface: STEP 1: Check the connectivity of the Class A  Surface Ensure that there is no gap between the component, using join command. We can visually check it or by clicking…

AIM: To develop a Master section with B side features. Screenshots of the completed design in various orientations: ISOMETRIC VIEW:   FRONT VIEW: SIDE VIEW: TOP VIEW:

AIM: Create the part models and assembly for the given drawings below with a report. DRAWING 1 (QUICK RETURN MECHANISM): REPORT ANALYSIS:Intially created the part of the drawing in the part workbench. Sketches and CAD Part:   After creating all the parts go to the Assembly Workbench and insert every part to the assembly…

AIM: Development of a Door Trim panel. OBJECTIVE: To make a Door trim panel in Catia V5 using the given Class A surface. ABSTRACT: This project contains the brief theory on how the approach has been made inorder to obtain the solid door trim panel. It also show case certain rules regarding the maufacturing of…

TITLE OF THE PROJECT: Advanced Sheet Metal design using NX CAD challenge 1 Casing Design. OBJECTIVE: To design a sheet metal casing design using Siemens NX sheet metal application. INTRODUCTION:  1) Sheet metal:  It is formed by an industrail process into thin, flat pieces, it is one of the fundamental…

TITLE OF THE PROJECT: Advanced Sheet Metal design using NX CAD challenge 2 Box Assembly. OBJECTIVE: To design a sheet metal casing design using Siemens NX sheet metal application. INTRODUCTION:  1) Sheet metal:  It is formed by an industrail process into thin, flat pieces, it is one of the fundamental…

TITLE OF THE PROJECT: Designing of a sheet metal part of odd shape. OBJECTIVE: To design a 'Sheetmetal part of odd shape' using Siemens NX Sheetmetal Application. INTRODUCTION: For studying different tools and features used for designing sheet metal design parts, this project was selected. This project was…

TITLE: Designing of Bracket using NX CAD Sheet Metal application. OBJECTIVE: To model an L-shaped bracket with given 2-D input. INTRODUCTION: Sheet metal brackets have a variety of applications in the automobile industry. Depending on the application and working conditions different materials can be used to create…

TITLE: Advance Sheet Metal using NX CAD  Challenge 7 metal bracket II. OBJECTIVE: To design a metal bracket II using Seimens NX Sheet Metal application. INTRODUCTION: 1) SIEMENS NX: NX formerly known as "unigraphics", is an advanced high-end CAD/CAM/CAE, which has been owned since 2007 by Siemens PLM Software.…

OBJECTIVE: Mesh the Given component with the Size of 5 Units. Create 1D elements on the following component with given cross-section and DOF. CAD MODEL: PROCEDURE: Step 1: Create the Midsurface using the command midsurface  in 1D for both the bracket and give the colours.   Step 2: Now create the material…

OBJECTIVE: To create midsurfaces and mesh the given components by satisfying the required quality criteria.   PROCEDURE: Import Model: To import the cad model, goto New model > import geometry and select the file to import.   As only shell meshing is to be performed, Solids are not necessary. Hence, Goto…

AIM : To create a tetramesh for different objects given with the specified quality criteria. OBJECTIVE:  (i) Use standard tetramesh technique to mesh the components. (ii) Generate 2-d tria elements mesh on the hub and cover. (iii) Check the quality of the tetra elements.   CAD IMAGE:   PROCEDURE: Import…

AIM : Mesh the given geometry. OBJECTIVE:  1) Mesh the given geometry. 2) Create connector as specified above.   CAD MODEL IMAGE : PROCEDURE : 1) Intially Import the required file. (.i.e Frame assembly.stp) 2) Perform Cleanup if required. 3) Now Mesh the surface and check for the quality criteria. 4) Check for…

AIM : To Mesh the given Rear Wheel Holder  component. OBJECTIVE : To Mesh the given Rear Wheel Holder  component using given mesh Quality and should pass all the criteria. CAD MODEL : PROCEDURE :  1) Import the file named Project2.iges. 2) Using the geometry menu in the menu bar, use the geometry cleanup tools to ensure…

AIM : To mesh the given component and create proper mesh flow. OBJECTIVE :  1) To Mesh the given Side Door Panel and create proper Mesh flow. 2) Pass all the Quality Criteria. 3) Assign the Thickness to the Component.   CAD MODEL IMAGE: PROCEDURE:  1) Import the file named as Side door.stp  2) Using the geometry menu in…
