Points to be followed in report Title of the Project - concept modelling of alloy Wheel Objective - To make a model of a alloy wheel usiang alias Introduction - Concept modeling of alloy wheel is starts from where 3d data takes shape, it is a part of process as every part is involved in it. the design is depends on every…

Title of the Project - Concept Modeling of Car Bumper Objective - To make a model of front bumper of fiat abarth 500 with the help of two views Introduction - concept modeling is the Modeling of here 3D data starts to take shapes, It is crusheal part of the process as every part is involved in this design process…

Title of the Project - Designing of car fender using Concept modelling techniques Using alias Sftware Introduction -          fender is a Side part of vehicle which is upper side of wheel. In this project main objective is  to design its only front image in single view Design methodology /…

Title of the Project  - MAKING CAR STEERING WHEEL IN AUTO DESK ALIAS Objective - To create the curve network and surface making for the car steering wheel  Introduction - In this I have learned about curve networks and also surface making. For this challenge I went into the entire curve networks…

  Title of the Project -   DEVELOPMENT OF KIA SPORTAGE USING ALIAS AUTO STUDIO Objective - To build the car using the Curves traced from the given blueprint of the car model. Introduction - Concept Sculpting is more interesting and skill full work, where we can bring our design from paper…

CONCEPT MODEL OF SEATS OBJECTIVE: To create a concept model of seats by using a proper curve network and curve and creating the surface and mainly depending on visualization. INTRODUCTION:          Auto Alias is a family of CAID software predominating used in automotive design and…

Title: Rendering of a model.   Objective: To be able to render a model and export it as images Introduction: This project is focused on rendering the model which is the most important part of designing because in modeling anything we have to present it in a realistic view that we visualized the model in such a way…

AIM:  Download the connectors & Connector clip cad data from given link & define it as Electrical Connector using Electrical Part design Workbench. Discriptions -         CONNECTOR DEFINATIONS IN CATIA V5 1. Deutsch DT06 – 08SA  * Create midpoint on the contact face…

Q1. Download following cad data & define it as Electrical support using Electrical Part design Workbench. Define all the necessary properties. P clamp Ans -    process: Create two points one as entry and another as exit point. create planes at two points and another at base. Switch to Electric part desgn…

Q1. Route the following harness layout in Electrical workbench. Make assumption for harness bundle diameters. Use Following connectors as shown in layout diagram. Add protective covering on all branches connected to DT06-2S & DT06-4S connectors. Keep end extremity at 30mm (from connectors end)   Download connector…

Q1. Route the following harness layout in Electrical workbench. Make assumption for harness bundle diameters. Use the connectors provided. After completion of routing, Check the bundle Continuity. Add snap of result in submission Add annotation to all connectors. Make an assumptions for annotations like connect 1 , 2 etc…

Ans-   AIM: TO FLATTEN THE WIRING HARNESS AND DRAFT THE WIRING HARNESS ASSEMBLY.   Week 4 Challege Design -      HARNESS FLATTENING: WE GO TO THE HARNESS FLATTENING WORKBENCH AND DEFINE THE FLATTENING PARAMETERS. WE USE THE EXTRACT COMMAND TO BRING THE HARNESS ASSEMBLY TO THE FLATTENING WORKBENCH…

Aim- To route the wiring harness on given Engine and flatten view drawing in CATIA V5. Description -     1. Creating Context Assembly    2. To define 4-pole connector electrically    3. Adding connectors to the all 16 fuel injector sensors and 4 cam-shaft sensors    4. Adding…

                                                        BACK DOOR WIRING HARNESS ROUTING AIM: Route the wiring harness on the Given car body and Prepare to flatten view drawing…

Aim: To be able to create solid from the given Class-A surface, by considering tooling axis and draft analysis.     Class-A surface given: A point was created at the center of the large circle, Using that axis system is inserted, Tooling Axis: Using the ZX plane an intersection is to be made. ' Two lines need…

Aim: To be able to create solid from the given Class-A surface, by considering tooling axis and draft analysis. Class-A surface given: A point was created at the center of the large circle, Using that axis system is inserted, Tooling Axis: Using the ZX plane an intersection is to be made. ' Two lines need to be created……

- Aim: Create the Switch Bezel Plastic component through the given Class-A surface. - Objectives: - To create class B & C surface for the given component. - To form the tooling axis and capture the surface properly. - To check the feasibility of the component with a draft of 3 degrees. - Method: - In…

AIM Create the Bumper Plastic component through the given Class-A surface.    INTRODUCTION A bumper is a structure attached to or integrated with the front and rear ends of a motor vehicle, to absorb impact in a minor collision, ideally minimizing repair costs.   OBJECTIVE To design Bumper as per automotive…

AIM Create the component through the given Class-A surface.  the tooling axis for the given Class-A Surface should be created meeting the requirements of the draft angle and at the end perform the Draft analysis on the model. Create the rib and screw boss as by considering the design rules   CLASS A…

Dog house design for the Door Trim:   Aim: Create the Dog House for the Door Trim considering the design rules and perform the draft analysis for class A and create the final close body component and perform the draft analysis. Objective: Create the Tooling axis  Design the class-B and class-C surfaces and…

Objective: The main aim of this challenge is to create a solid body of 'Door Trim Lower' with the help of the closed surface method by using the 'Generative shape design' workbench in CATIA V5. Performing the 'Draft Analysis' on the solid part body of the Door trim. Overview:Initially, we need to offset the given Door…

 Prepare a report explaining what is Bench-Marking -  Bench-Marking -  It is an organised comparison of similar goods, services, or methods along some performance variables. By benchmarking one can include the better options available in competitors and eliminate the bad ones. This results in the development of the best…

Under-Body Coating: Underbody coating is usually a dense cladding (often based on rubber) applied uniformly to the undercarriage of the automobile. It is normally sprayed or painted on when the car is just out of the dealership and is clean. But even if you are getting the undercoating applied after a couple of years,…

1) AIM :- Create the A pillar plastic part from the given Class A surface, considering the design rules using master section and perform the draft analysis. 2) INTRODUCTION :- A. DOG HOUSE :- Dog house is an engineering feature used in plastic design. Dog houses are used as support feature. Sometimes other engineering…

Quick return Mechanism -            Product 2 - CV Joint

AIM: To design the Hood or Bonet of the front driving car by using the master section and standard procedure which is used in the OEM Manufacturer's. GIVEN MASTER SECTION: HOOD or BONET: Hood is the component which is placed over the engine compartment. The design of the hood is not only to enhance the look of the car,…

Aim  To calculate the section modulus of the previously designed hood for analyzing its strength and also optimizing the design to see the difference in the bending strength of the hood. Higher the section modulus of a structure, the more the resistive it becomes to bending. Section modulus Section modulus is a geometric…

Aim: To decide whether the given design passes the European standards or not.   Given Design:   European Regulations Requirement:   Take the outline of the wheel and the fender. Make the centre of the wheel circle. Draw horizontal and vertical perpendicular axes from the centre of the wheel circle.…

FENDER DESIGN AIM: To design a  front fender of a car by following the given master section as per the design considerations of OEM. FENDER It is an aesthetic component/part of a car that frames the wheels. Prevention of sand,  mud particles, and other road contaminants from being thrown into the engine…

 ROOF DESIGN   OBJECTIVE : The objective of this project is to design car roof with  essential flanges and reinforcements  like ditch area , front roof rail , bow roofs, central roof rail and rear roof rail for the the given styling surface Perform a curvature study on the roof and perform the calculations…

Aim :         To develop the car Backdoor(Tail gate) with the reference of given skin data as per engineering standared by using NX12 Back Door :          The Back door is typically hinged, but sometimes attached by other mechanisms such as tracks, in front of an opening which is used for entering and exiting a vehicle. …
