1a) AIM : To create a revit file and  Naming a file TOOLS/COMMANDS REQUIRED :  file menu  open PROCEDURE :  A. first when we open the autodesk revit app after opening the app we will find a file icon on the top left corner. B. on clicking on that icon we will get adrop down menu, that we should click on new option, and…

1a) BIM : BUILDING INFORMATION MODELLING In revit BIM is rather than a software it is process. Mainly BIM is divided into two core concepts they are:  A. Coordination B. Computation  Using autodesk revit we can get coordination with multiple disciplines If we think revit as a BIM tool it will perform computations…

1a)  AIM : To create the floor plan for the given layout, Align the floor plan with grids. TOOLS/COMMANDS REQUIRED : Acrchitecture TOOL View  Elevation Grid Annotate  Align   PROCEDURE : Browse the saved layout. In the toolbar you will find the view tool we have to open that' we will get the…

1a)  AIM : To Model a Ceiling from architecture tab above the walls at first floor level TOOL/COMMANDS REQUIRED : File  Architecture Ceiling Sketch ceiling Ceiling plan view PROCEDURE : we have to browse the saved file from the saved project. In that we already have a first floor and second floor along with the…

1) Why are building and gneral  codes or standards essential for the modeling/ efficiency of drawings in Revit ? A) The building codes are mainly required to protect public health, safety and genearal welfare as they are related to occupancy and construction of buildings and structures. The building standards becomes…

1) Open an architectural template. Using Manage tab set project base point and project shared coordinates for the project A) AIM:- Set the base point of the project using manage tab and project shared coordinates for the project Commands/Tools used: Architectural Manage Grids Procedure: Select the Architectural tab and…

1) Select the type of structure you want to build from one of the three below        a. Multi Unit Residential Apartment        b. Office Buildings        c. School. A) From the given three above options i have selected Multi Unit Residential Apartment.  …

1) What are HVAC systems ? Why are they essential in modeling of buildings? A) HVAC stands for  Heating, Ventilation, and Air Conditioning. The HVAC system modeling implies to the modeling of building, indoor, outdoor, and air handling unit (AHU) equipments. It is normally difficult for one HVAC system model…

1) Use the shortcut keys in Revit discussed in class to complete the following tasks and list them below           a. Using 3D model create a section box           b. To create similar doors and windows in a floor plan layout         …

1)Create a G+4 Residential building as per NBC standards and make it a central model file. Your model should contain: The sloped roof at the top level of the building (10 degrees) Architectural components including furniture and home appliances Room tags and Annotations Section cut through each room either longitudinally…

1) Using Dynamo create a set of sinusoidal points and create a curve and create a surface out of the curve? A) AIM:To draw a curve by using a set of sinusoidal points and create a surface to it.   TOOLS USED :  Architectural template  Manage   Dynamo PROCEDURE : Open an architectural template.…

1) Use the Architecture/ Structure Project file developed by you in Week 6 to 8. Export the Revit architecture and structure model to Navisworks Cache file following the export settings discussed in class? A) AIM:- To export architectural/structural model to navisworks cache file. TOOLS/COMMAND REQUIRED:-    …
