Design of American Chopper   Objective :  To learn the features and tools used in designing n industries in Solidworks. …

                                                                                Benchmarking       1.…

                                                                      UNDERBODY COATING    A car’s underbody is exposed to the…

                                                                                         …

                                                              Hood Design Introduction Hood is the outer panel covering the engine compartment in the front of the car…

AIM: Create the Base Bracket Plastic component through the given Class-A surface. To begin with, the tooling axis for the given Class A Surface should be created meeting the requirements of the draft angle and at the end perform the Draft analysis on the model. REPORT ON DRAFT ANALYSIS: Given Class A Surface: STEP…

- Aim: Create the Switch Bezel Plastic component through the given Class-A surface. - Objectives: - To create class B & C surface for the given component. - To form the tooling axis and capture the surface properly. - To check the feasibility of the component with a draft of 3 degrees. - Method: - In…

COIN HOLDER To create a coin holder plastic component by closed method with reference to the class A surface and do the draft analysis for the component. Steps followed The class A surface is checked for the connectivity of the surface and ensure it is completely joined and there will be no gap between the surfaces. If…

BUMPER DESIGN   AIM: to make a model from the provided class-A surface.INTRODUCTION:CLASS-A SURFACE: a surface made by the designer which is given as an input to the plastic modeler to work on. It is aesthetic surfaceand the outer most surface. CLASS-B SURFACE: a surface below a certain thickness from…

Aim : To create the class B surface, C surface and tooling axis also publish it as well as close surface the given door trims. Objectives : Create the Door Trim Plastic component through the given Class-A surface. To begin with, the tooling axis for the given Class-A Surface should be created meeting the requirements of…

CORE AND CAVITY DESIGN AIM: To Create the Core and cavity blocks for the switch bezel component. DESCRIPTION:   1. CREATING TOOLING AXIS -                       The Tooling Direction is basically the direction that the mold pulls a part. The mold is…

Boss) AIM: To Create the Door Handle Component from the given Class-A surface. To Create the tooling axis for the given Class-A Surface meeting the requirements of the draft angle. To Attach B side Features in the component. To perform the Draft analysis on the model.  TOOLS USED: Boundary Join Multiple extract Bisecting…
