Frequently Asked STAAD.Pro & AutoCAD Interview Questions and Answers



Structural Analysis and Design is abbreviated as STAAD (or STAAD.Pro). Research Engineers International created STAAD.Pro as a computer application in Yorba Linda, California, in 1997. Research Engineers International purchased it in late 2005.

In the subject of civil engineering, STAAD.Pro is now the software application that is used the most.

Users of AutoCAD may only make fundamental adjustments to 2 dimensions. Students who have completed a STAAD.Pro course can work on 3D or three-dimensional models in great detail using the software, on the other hand. Your manual computation time and effort are significantly reduced using STAAD.Pro.



Common Interview Questions on STAAD.Pro & AutoCAD that You Should Know

Today, there are countless prospects for AutoCAD and STAAD.Pro specialists worldwide. Skill-Lync has compiled all the crucial concepts that could be questioned during an engineering interview.

Check out the AutoCAD interview questions and answers below if you want to start a career in this area. You'll gain a competitive advantage that will help you succeed.





• How can AutoCAD be used to create a user interface?



This is the most typical interview question for any civil engineer. Using command prompts, a user interface can be created. It will include conversation boxes and storylines. The dialogue boxes can be examined using the PLOT command and the external database commands (ASE). Set CMDDIA to 1 to launch the dialogue windows. The command line must display the complete file so that it can be easily edited or customised.



• What use does "variant" serve in AutoCAD?



In AutoCAD, variations are used to help conceptual, create, and render 3D models that involve 3D printing. They allow you to use the features of the various applications as necessary.



• Why do mobile users prefer AutoCAD WS more?



The answer is that designers of mobile applications have several options thanks to AutoCAD WS. Designers may edit, view, and share using AutoCAD. They may easily offer the application wherever they go and can quickly create an application. Without regard to the authorising problem, the application can be downloaded and installed from any place on the planet.



• What file format does AutoCAD use for design?



The .dwg file is the default format in AutoCAD. The format can also be changed. It offers a variety of languages that can be employed depending on the situation.

The interchangeable file setup maintains the DXF extension. The interchangeable DXF file extension signifies the data operability of the file format.



Now, Let's focus on some of the STAAD.Pro interview questions and answer the following section, which candidates face pretty often.





• Which structures would require less volume of materials?



Statically indeterminate structures would consume less volume of material and have excellent stability and can support a loading with thinner components.



• If consecutive structures in an internal beam are identical, what will be the measurement of its tributary area?



Due to the similarity of the structures, the triangle's angles will be 45 and 90 degrees.



• What should be the bare minimum number of joints necessary for the stability of an equilibrium equation if a structure has a total of 10 joints?



Equilibrium equations must be simultaneously satisfied at every joint of the structure for stability. Thus there have to be 10 joints.



• What is the maximum permissible reduction per cent in the case of a structural member supporting more than one level with a load above 100 psf?



Studies have revealed that a floor is rarely loaded with more than 80% of its design load in more than one-storey structures. Hence 20% will be the correct answer.



• How many unknowns would there be in a structural system if we used link support?



If link support is applied, there will be 1 unknown, which is the force operating along the axis of the link.



• Which building material doesn't go into the construction of trusses?



Although concrete is preferred over other materials for its high compression yet, due to its weakness in bearing tension, we should avoid using concrete in the construction of trusses.



Some Additional Interview Questions on STAAD.Pro for Experienced Candidates

• What would you do if you discovered that a contractor had performed subpar work?
• Describe the various flow profiles.
• Define the crack width limit and discuss its importance.
• What is a site of particular scientific interest (SSSI), and what kinds of constructions can be erected there?
• Which public structure or monument do you feel to be structurally the most interesting?
• Discuss the need for BIM for engineering and construction projects.
• How can construction projects maintain local rules and regulations?
• What different methods are there for enhancing a pipe's flow capacity?
• How to examine the procedure for inspecting property during and after construction?



Conclusion

Computer-Aided Design (CAD) models for architecture and engineering are created and programmed by AutoCAD and STAAD.Pro drafters. They are experts in using both software, creating solid and surface models from scratch and simple blueprints and design schematics.

Applicants for the interviews must possess an in-depth understanding of STAAD.Pro and AutoCAD software, complex design abilities, and practical communication skills.
