Week 6 - Creating connection for Rear door

Ansa July live batch 1   Aim: in this challenge we have to do morphing using Ansa Morphing is an adaptation of given shape to a new form. The geometry of a given concept model can be modified to required proportions to create new designs. CAE Morphing allows users to work on the FE mesh directly reducing the time…

Ansa july live batch 1   Aim: create connections for the rear door by using different 1D elements and Create and Apply different PIDs for different components    1D elements are used when one of the dimension is very large compared to the other two.If a large number of bolts are to be modeled, then the use…

plastic model =5 hrs  sheet metal = 3 hrs

Ansa july live batch 1   Aim  :   In this plastic  model we have to create the midsurface after checking the geometry errors, and mesh the component with the given quality criteria and after that assign the thickness. S.No  Quality Criteria  Value  1 Target/Average length  …

.

  Ansa July live batch 1   Aim: For the given Rear view mirror component, check for the geometrical errors and mesh the Surfaces with the given 2D element Quality criteria’s given below. Given: S. No  Quality Criteria  Value  1 Target/Average length   1 2 Minimum Length  0.5…

 Ansa July live batch one Aim :   In this model we have to create the midsurface after checking the geometry errors,  mesh the component with the given quality criteria and after that assign the thickness.Given :S.No Quality Criteria Value 1Target/Average length  52Minimum…

Objectives: Create a tetramesh for Housing component with the following quality criteria.                    Create a 3D tetramesh with the following quality criteria. Procedure: For model one Import the CAD model. Check for geometry cleanup. Initially mesh the model in…

  Objectives: mesh the hood component with the given quality criteria and assign the thickness and material. Given: Target element length =5 units               Element type(mixed).   Stepwise procedure: There are four sub-parts in the hood component: Inner-extract. Outer-extract. Hinge-reinforcement extract. Latch-reinforcement…

Aim: Mesh the Given component with the Size of 5 Units. Create 1D elements on the following component with given cross-section and DOF objective: Rod element:- Translational DOF should be Constrained with RBE2 link Cross-Section: BOX- Dimension a= 12 mm                  …

Aim:  parsing NASA thermodynamic data   objective: Write a function that extracts the 14 co-efficients and calculates the enthalpy, entropy and specific heats for all the species in the data file. Calculate the molecular weight of each species and display it in the command window.  What is file parsing:…

Aim:  optimise the stalagmite function and find the global maxima of the function. Objective: 3 case study of 3 case of options using Genetic Algorithm. find out the global maxima optimizing  stalagmite function. Coding of stalagmite function in matlab. Genetic Algorithm: The genetic algorithm is a…

Aim : solving  second order ode using matlab. Objective:   write a program that solves the following ODE. This ODE represents the equation of motion of a simple pendulum with damping.   In the above equation, g = gravity in m/s2, L = length of the pendulum in m, m = mass of the ball in kg, b=damping…

       Challenge-skill lync -MAYUR SHINDE  Aim :  forward kinematics of 2R robotic arm manupulater. Objectives : Kinematics of linkagers.Animate the two linkages of robotic arm using matlab . Problem statements:   How the robot is going to move. What is the final position of manupulater…
