Sanjay Singh
You Dream it, We Build it
Introduction
10 Projects
Week 1 Challenge
Aim: To calculate the dead load of bridge and apply it in staad pro and perform structural analysis. Given data: Location of bridge= 60KM within radius from the Bay of Bengal Type of bridge= RCC box girder bridge Width of the bridge deck=10.2M Span of bridge=12M Pier diameter=2.5M Seismic zone=IV Wind speed=47KM/hr…
25 Jul 2022 06:59 PM IST
Week 2 Challenge
Aim: To apply the IRC live loads and model in Staad pro and perform the structural analysis. Given data: Width of the bridge= 7m Span of bridge=24m Pier diameter= 2m Wind load= 42km/hr Unit weight of soil= 18kN/m3 Location of bridge in seismic zone III Theory: Live load: The live load on the bridge, is moving…
01 Aug 2022 12:53 PM IST
Week 3 Challenge
Aim: To apply the IRS live loads and model in Staad pro and perform the structural analysis. Given data: Width of the bridge=26 Span of bridge=25m Pier diameter= 10m Type of bridge= I girder bridge Theory: Live load: The simply supported structures shall be designed for one of the loading envelopes (Light,…
13 Aug 2022 10:54 AM IST
Week 4 Challenge
Aim: To calculate the Earth pressure acting on the abutment wall and apply on Staad pro. Given data: Length of the abutment wall=5M Height of the abutment wall =10M Height of the backfill soil =7M Height of ground level from foundation top =3M Height of foundation =1M Water table at ground level Density of…
18 Aug 2022 05:53 AM IST
Week 5 Challenge
Aim: Calculate the design wind loads for the bridges and apply the wind load in Staad.pro. Given data: Location: Mumbai Height of bridge: 9m Pier size: 1.5X1.5m In open terrain with scattered obstructions of height less than 10m. Theory: Wind load is an important consideration when designing and building…
22 Aug 2022 12:26 AM IST
Week 6 Challenge
Aim: Calculate the pipe loads for the bridges and apply the pipe load in Staad.pro. Given data: Location: Narmada River Width of bridge: 3m Diameter of pipe 1: 700mm Diameter of pipe 2: 200mm Length of bridge: 24m Pipe type: Class k9 DI pipe Unit weight of class 700 k9 DI pipe: 2.17KN/m Unit weight of class 200…
26 Aug 2022 06:24 PM IST
Project 1
Aim: Calculate the dead load, IRS live load, Earth pressure load, wind load and seismic loads for the bridge structure and applying these loads on STAAD Pro. Given data: Unit weight of soil = 18kN/m3 Location of the bridge = Ahmedabad Wind load calculation as per IS 875 Seismic load calculation as per IS 1893 STAAD…
31 Aug 2022 11:37 AM IST
Week 7 Challenge
Aim: To calculate the water current forces of the bridge and apply in the staad pro. and perform structural analysis. Given: Span of the bridge = 45m Mean velocity of the river = 3m/s High flood level = 2m above the foundation level Diameter of the pier = 1m Height of the pier = 3.965m Thickness of the foundation…
04 Sep 2022 08:16 PM IST
Week 8 Challenge
Aim: To calculate the centrifugal load of the bridge and apply in the staad pro. and perform structural analysis. Given data: Span length = 12m Width of carriage way = 7m Live load = 70R tracked vehicle Speed of vehicle = 75 km/hr Radius of curvature = 3m Theory: The moving of a vehicle in a curve produces…
13 Sep 2022 07:22 PM IST
Week 9 Challenge
Aim: To calculate the wave load on the superstructure and apply in the staad pro. and perform structural analysis. Given data: Span of the bridge = 12m Width of deck slab = 9m Thickness of deck slab = 2m Maximum crest elevation = 3m Height of I girder = 1.7m Width of top and bottom flange = 2.5m Thickness of flange…
17 Oct 2022 04:26 PM IST
Academic Qualification
B.E
Technocrats Group of Institutions
06 Aug 2014 - 11 Apr 2018
12th
Rewanchal Public School
01 May 2012 - 19 Apr 2013
10th
Rewanchal Public School
01 May 2010 - 21 Apr 2011
