AIM & OBJECTIVE To create different parts of a American chopper in Solidworks using various types of sketches and features tools. To assemble the different modelled parts to create the chopper. To create photorealistic rendered images of the chopper using Solidworks Visualize. INTRODUCTION  The chopper was modelled using part…

RADAR MAST --------------------------------------------------------------------------------------------------------------------------------- ASSEMBLY OF YATCH   OBJECTIVE:- To design and draft the individual parts of the yatch and assemble it and render it with photoview 360. INTRODUCTION:- A yacht is a…

 OBJECTIVE: To design an advanced casing using the sheet metal application in siemens NX. INTRODUCTION: Sheet metal design is a vast domain in the design of any sheet metal industry,it is used many sectors including the aeronautics & automotive sectors, in this sheet metal casing design we will look at the design…

Objective:To design a Box assembly by using Siemens NX sheetmetal Application. Introduction:NX Siemens contains a series of applications that support different workflows, such as creating parts, building an assembly, or producing a drawing. And NX Siemens sheetmetal application provides an environment for the design of…

DESIGN OF SHEET METAL ODD ENCLOSURE USING NX CAD   OBJECTIVE: The objective of the project is to design a sheet metal odd shaped enclosure using Sheet metal application in Siemens NX and a drawing sheet needs to be drafted for the designed model using drawing application in NX. INTRODUCTION: NX sheet metal…

SHEET METAL DESIGN USING NX CAD (BRACKET) OBJECTIVE: To design a bracket using NX CAD sheet metal application. INTRODUCTION: Sheet metal Design provides the design professional with a complete set of tools to efficiently create and manage sheet metal parts based on the knowledge of materia properties and manufacturing…

OBJECTIVE: To understand the step by step procedure to design the metal bracket using NX CAD INTRODUCTION: Sheet metal parts are known for their durability, which makes them great for end use applications. Parts used for low volume prototypes, and high volume production runs are most cost-effective due to large initial…

BENCHMARKING Benchmarking involves a structured comparison between similar products, services or processes on some dimensions of performance. It is particularly useful when comparing not only performance but also practice in other words what do the different organizations do to enable that performance to be delivered.…

UNDERBODY COATING Underbody coating is a thick resilient coating applied to the underbody or chassis of an automobile to protect against impact damage from small stones, which would rapidly chip ordinary paint, allowing rusting to begin. Historically, a bitumen-based compound was used, but after approximately a decade,…

OBJECTIVE: The main objective of this project is to design the Hood of a car that satisfies the manufacturing requirements, functional requirements, and as well as Euro NCAP standards. The Body in white (BIW) inner panel and outer panel of the hood must be designed and assembled with the Hinge Assembly, Latch and Striker…

AIM: The main aim is to design the fender model with the necessary mounts using NX CAD. The mounts which we need to design are as follows Drip Bumper A-Pillar Sill Cowl FENDER Fender is the American English term for the part of an automobile, motorcycle or other vehicle body that frames a wheel…

INTRODUCTION: Section modulus is a direct measure of the strength of any sectional area of an object about a reference axis (neutral axis). This strength can measure directly from the Section modulus formula and is defined by the below formula. Section modulus is represented with a symbol of 'S'.                      …

Objective: To design the Automotive Roof based on the given styling surface and to analyze the prepared model to check the manufacturability and the feasibility of the design. To perform the section modulus study for the master sections and create for the Front roof rail, Rear roof rail, Bow roofs and center roof rail.…

AIM: To develop the car Backdoor(Tailgate) with the reference of given skin data as per engineering standard by using NX12 BACK DOOR: The Back door is typically hinged but sometimes attached by other mechanisms such as tracks, in front of an opening that is used for entering and exiting a vehicle. A vehicle door can be…

THE ABOVE MODELS ARE BEEN DOWNLOADED, ARE ADDED TO THE CATALOGUE IN THE CONNECTORS FAMILY AND ARE ELECTRICALLY DEFINED WITH THE GIVEN PROPERTIES ADDED FOR THEM. THE FILES ARE BEEN ATTACHED BELOW.

The complete files are uploaded below in the zip file.

.

PICTURE FLOWCHART OF DRAFT ANALYSIS OF FAN COVER. Analysis for the angles ranging between -20 to 20 degrees draft angle.     The draft is defined as molded parts to make them easier to remove from molds. There are two of determining the objects to draft either by explicitly selecting the object by selecting the…

AFTER DRAFT ANALYSIS, WE OFFSET THE RIBS AT FIRST AND UNTRIM, EXTRAPOLATE AND TRIM THE SURFACES TO FORM A "B SURFACE". AFTER THAT WE CREATE C SURFACE AT A DRAFT ANGLE OF 3 DEGREES USING SWEEP COMMAND.

CLASS A SURFACE CLASS B SURFACES ARE ATTACHED BELOW CLASS C SURFACE FINAL TRIM DUE TO LACK OF TIME, I UNABLE TO COMPLETE DRAFT ANALYSIS.

GIVEN CLASS A SURFACE DESIGNED CLASS B SURFACE DESIGNED CLASS C SURFACE FINAL COMPLETE PLASTIC SURFACE AFTER EVERYTHING JOINING TOGETHER CLOSED SOLID MODEL

CAVITY BLOCK CORE BLOCK PARTING SURFACE AND PARTING LINE COMPLETE CORE CAVITY BLOCKS

DRAFT ANALYSIS.

DRAFT ANALYSIS FOR CLASS A SURFACE CLASS A SURFACE EXTRACTED CLASS B SURFACE CLASS C SURFACE FORMED CLOSED SURFACE 4 WAY LOCATORS, 2 WAY LOCATORS AND HEAT STAKES CLEARANCES FOR THE COUNTERPART
