1.1 open the revit > New>project>select template file>choose Project>ok 2.1 File>save>choose folder( or create new)> name of the file>save 2.2 file>close  File>open>choose folder>select file>open 3.1 Architect>wall>select type of wall>selct rect >  apply dimension…

A1. Building Information Modeling (Bim) allows professionals to explore a project’s key physical and functional characteristics digitally, before it’s built. . It is used by many trades for design, construct, operate and maintenance for gas, electric, roads, railways, bridge etc.  Aim is to find and fix the mistakes before…

A1. click on Arch> Floor and Floor Architect> Select Generic 12"> Pick the line from sketch.>complete the boundary as necessory ARCH>LEVELS CREATED LEVELS as below. ARCH>GRID. CREATED GRIDS as below.     A2. ARCH>WALL- CREATED 9" WALLS AND DRAWN ALL 9" WALLS as per 2d drawing layout  …

A1 ARCHITECT>CEILING> CHOOSE THE TYPE OF CEILING >SKETCH CEILING> DRAW BOUNDARY>CLICK TO FINISH.     Aim is to hide electrical wire for devices like Lights, HVAC ducts etc.. CHECK THE RESULT ON 1ST FLOOR.    A2.  ARCHITECT>ROOF>SELECT ROOF TYPE>ROOF MOVE TO FL-4, CLICK…

ANS1:  BUILDING CODES ENSURE THE STRUCTURAL INTEGRITY LIKE ELECTRICAL, MECHANICAL PLUMBING - ALL THE TRADES SAFETY AS WELL AS ACCESSIBILTY AND PRACTICAL AND ACHIVABLE LEVELS OF ENERGY EFFICIENT. ALL THE ARCHITECT, ENGINEERS, BUILDERS, INSPECTORS, AUTHORITY, AND DEVELOPER FOLLOWS THE BUILDING    ANS2: RESIDENTIAL,…

ANS1: AIM MANAGE>SPECIFY CO-ORDINATE>SELECT HOR GRID> NORTH/SOUTH   = 0 SELECT VERT 1ST GRID> EAST/WEST  = 0 SAVE. ANS2: AIM FILE>NEW>STRUCT TEMPL>PROJECT >OK...SAVE....   ANS3: COLLABORATE>  SAVE AS IN NETWORK> ANS4 STRUCTURE>GRID ANS 5:  OPEN >CLOSE>SAVE…

ANS1: I SELECTED RES. HOME WITH 3 STOREY.  ANS 2: OK ANS3:  a> added foundation . b> added column and beam . c>bean connection FILED. in need SUPPORT for why connection shows WARNING ( caution sign) , then I would be able to add connectiion to base and top.  d>ADDED truss under the roof.  …

Ans2> split systems, hybrid systems, duct-free systems, and packaged heating and air systems (PTAC) They are essential to control the climate ( temp, humidity) within the buiding compare to outdoor weather.  HVAC sytems help to incease efficiency of humans, equipments.  ANS2> Added HVAC  system…

A1.  Installed NW Exported from autodesk and Installed. save to folder Arch model file.  Saved Structural file      Ans 2: Walk around Walk around recorded to make animation. Frames are on the right side   Ans 3: Above is Realism walk though from outside of Home to Inside the Kitchen. Ans…

Ans 1: a>  Turn On Section box under Property.  Adjust the sizes by dragging arrow keys. 2>Select Door or windows or any elements &  Type CS  and drag it to new location.   c> Go to Structural or Floor  plan and Type TL will make Thin line or make thick line depending on the setting…

Ans 1> following parameters requires 1: code block ( multiple blocks)  2: range 3: Point by Co-ordinates 4: Number of slides 5: product 6: addition 7:Line numbercurve 8: Interger Slider 9: Custom node property 10: List create 11: Surface by loft ANS 2> 1: Number of Slides 2: Point by co ordinates 3: line by startpoint…
