Detailed Report On Draft Analysis - Draft Analysis is the process of analysing each surface of a Class A surface along the considered Tooling Axis.  Why Draft Analysis ? The primary purpose of Draft Analysis is to see if all faces of the Class A surface clear the Tooling Axis. This way, we can confirm if the Tooling…

Draft Analysis -  The process of checking every face of the Surface to see if it clears the tooling according to the direction given as the Tooling Axis. For this we first need to decide a Tooling Direction and using that make a Tooling Axis. The process of making the tooling axis is as follows - Perform a visual…

Draft Analysis -   The process of checking every face of the Surface to see if it clears the tooling according to the direction given as the Tooling Axis. For this we first need to decide a Tooling Direction and using that make a Tooling Axis. The process of making the tooling axis is as follows - Perform a visual…

Draft Analysis - The process of checking every face of the Surface to see if it clears the tooling according to the direction given as the Tooling Axis. For this we first need to decide a Tooling Direction and using that make a Tooling Axis. The process of making the tooling axis is as follows -  Perform a visual…

Draft Analysis - The process of checking every face of the Surface to see if it clears the tooling according to the direction given as the Tooling Axis. For this we first need to decide a Tooling Direction and using that make a Tooling Axis. The process of making the tooling axis is as follows -  Perform a visual…

Draft Analysis -  The process of checking every face of the Surface to see if it clears the tooling according to the direction given as the Tooling Axis. For this we first need to decide a Tooling Direction and using that make a Tooling Axis. The process of making the tooling axis is as follows - Perform a visual…

Why Draft Analysis ? The primary purpose of Draft Analysis is to see if all faces of the Class A surface clear the Tooling Axis. This way, we can confirm if the Tooling Axis we assumed after the initial Visual check is correct for our Class A surface and if it's okay to go on ahead and design the part considering the assumed…

Draft Analysis -  The process of checking every face of the Surface to see if it clears the tooling according to the direction given as the Tooling Axis. For this we first need to decide a Tooling Direction and using that make a Tooling Axis. The process of making the tooling axis is as follows - Perform a visual…

FINAL DOOR ASSEMBLY -  UPPER MAP POCKET  -CLASS B - CLASS C - PART BODY - DRAFT ANALYSIS - LOWER MAP POCKET  - CLASS B - CLASS C - PART BODY - DRAFT ANALYSIS - LOWER SUBSTRATE - CLASS B - CLASS C - PART BODY - DRAFT ANALYSIS - DOOR ARM REST (1ST HALF)  - CLASS B - CLASS C - PART BODY - DRAFT ANALYSIS…

 QUICK RETURN MECHANISM - PART 1 - PART 2 - PART 3 - PART 4 - PART 5 - FINAL ASSEMBLY - TREE STRUCTURES -       CV JOINT - PART 1 - PART 2 - PART 3 - FINAL ASSEMBLY - TREE STRUCTURES -

OOR ARM REST PRESENTATION - CLASS B SURFACE - CLASS C SURFACE - FINAL PART BODY - ISOMETRIC VIEW - FRONT VIEW - LEFT VIEW - RIGHT VIEW - TOP VIEW - DRAFT ANALYSES -  FROM MAIN TOOLING AXIS - As can be seen from the picture above, the man tooling axis clears all of the part body except for the screw base hole. To clear…

BENCHMARKING - Benchmarking is the process of standard comparision of mutiple similar products/services on a given set of performance factors. In Automotive Industry, there are different levels of Benchmarking namely, Benchmarking I & Benchmarking II.  Benchmarking I -  This type of Benchmarking is a more…

UNDERBODY COATING  Underbody coating otherwise called Undersealing is the process of spraying or coating a film of material in order to protect the metal or alloy components that are exposed to the road surface.  Most common problems faced by the underbody metal components are - Corrosion - This is caused because…

                                                                                           …

                                                                                                            IMPROVING SECTION MODULUS  Sectional Modulus is an important mechanical property for any part, because it tells us about the Load resisting ability of the part. This property becomes even more important when it comes…

                                                                                                               FENDER DESIGN REPORT   Fender is an important exterior component of an Automobile. Fender is the connecting link between the Bumper and the Sidedoor Panel. This is not the only purpose of the Fender. The Fender…

                                                                                           …

                                                                                                                            CAR ROOF ASSEMBLY The Roof of a Car is one of most important components in a Car. Along with providing a cover over our head from varying weather conditions (which is common knowledge), it serves…

Reasons for using Parametric Structure  This method helps in organising the Design process better.  This helps in tracking down the problem better (if any). This also helps implement changes easily.  Publication Publications are used to create a link between a few important parts in a Design. A Publication is basically…

                                                                                         …
