vijay M
Skills Acquired at Skill-Lync :
- MATLAB-BASICS
5 Projects
Week 4-1D Element Creation Challenge
Objective:To mesh the given modal and also create some 1D elements Procedure: 1.Open the modal and use autocleanup option for repair of modal. 2.Create Mid surface of both the brackets by Mid surfacing option in geometry command. 3.Give appropriate names corresponding to 2 brackets by use of organize option.…
19 Feb 2021 09:32 AM IST
Week 1 Stress Concentration on a Plate with hole
Aim: To simulate the 2 modals given and compare their deformation and stress developed and check which design suits best for analysis and manufacturing standpoint. Procedure: …
24 May 2021 06:59 AM IST
Week 1 Spur Gear Challenge
Objective:To perform the static structural analysis on a spur gear and find out the total deformation, Equivalent stress, Stress intensity and Location of fracture for the three materials given a nd compare them.Also conclude which material is the best one based on results. Procedure: 1.Open the ansys workbench.Select…
26 May 2021 11:19 AM IST
Week 12:Project-1-Meshing of Door Inner Panel Challenge
Objective: Meshing of inner door panel using hypermesh and assigning suitable thickness to them. Introduction: Learning Mid-surfacing and meshing of complex components like inner door panel is the main aim of this project. The input modal is shown below: There are…
03 Jun 2021 08:16 AM IST
Week 2 Bevel Gear Challenge
GRID DEPENDENCY TEST FOR BEVEL GEAR SIMULATION Aim: 1.To perform a Grid dependency test for bevel gear simulation for following mesh sizes: Case-1-Mesh size of 6.5mm. Case-2-Mesh size of 4mm. 2.To solve for Von-Mises stress,Equivalent elastic strain…
12 Jun 2021 11:39 AM IST
