Structural analysis of a buidling using Robot Structural Analysis

1)

AIM-Hvac systems and its essentials in modeling of buildings.

a.Heating ventilation and air conditioning

b.It is a technology of indoor environmental comfort.Its goal is to prrovide indoor thermal comfort and acceptable indoor air quality.

c.Important part of structure.

Essentials in building modeling

Control overall climate of the building.

It enhances the productivity.

It improves the air quality.

Achieving the energy efficiency.

2)

Aim-

To design a HVAC system for each floor to cover the topics included in the class.
a. Typical HVAC unit includes Distribution center
b. Collector
c. Ducts
d. Blower

3)

AIM- To Use the add-ins tab to load plug-ins for robot structural analysis to your Revit software.

Dowload and instal the robot structural analysis to revit from structural analysis toolkit from Autodesk.

4)

a)It helps to calculate loads and internal forces.

b)It helps to cross check the engineering design.

c)Can perform during design.

d)Can analyse each and individual elements.

5)

Aim-

To export the complete analytical model to robot structural analysis.

Procedure-

1)Prepare a structural model from the STR template

2)Assign the loads,load cases and load combinations on the structure.

3)Then export to the robot structural analysis and find the results.

6)

It is the traditional method of assessing the way the energy is used in an operation involving the physical or chemical processing of materials and transfer ot conversion of energy.

Principles

1.Calaculating heat loss and gain.

2.Calculating energy.

3.Determining the fuel requirement.

4.Evaluating the costs.
