Steps followed to define connectors & Connector clip as an electrical part in electrical part design workbench.1)Download the connectors and clip from the link in stp format and load them in catia(DT06 – 08SA, Tyco 174357-2, Tyco 85229-1)2)Create the Geometrical set like point at the bundle entry side,mating side and…

REPORT WRITTING FOR Q1:Steps to be followed to define the given P- Clamp as an Electrical suppot.1) Download the P-Clamp CAD model and load the file in Catia.2) Create the Geometrical parameters like points and planes required for defining the P-clamp as Support part in the part design module.3) Now, Switch to Electrical…

Steps to be followed to Route the given harness layout and to add the protective covering.1) Create a product(main) named "Wiring_harness_context"2) Create a new product(Sub) named "Geometrical_Bundle" and "Electrical_Bundle"3) Open the Geometrical_Bundle product in a new window and add all the components required (DT06-4S,…

Steps followed while Routing the following harness layout in Electrical workbench.1) load all the 10 connectors in catia and define all of them electrically in electrical past design workbench.2) Create a product with harness assembly assemblies named "Harness A" and "Harness B".3) Add the connecors in the respective harness…

Steps followed while Flattening and flattened view creation of the given wiring harness assembly1. Save the wiring harness assembly which should be flattened.2. Create a new product and (add the catalog when required) use the "Harness flattening parameters" command to add the parameters. Save the file in the folder where…

Assignment: Route the Wiring harness on Given Engine and Prepare flatten view drawing in CATIA V5. The first step involved in Wiring harness design process is "Input Collection".All the required data like Physical Architecture (gives the location of the components), BOM(Bill of Materials), Vehicle Specification (Assembly…

Assignment: Route the Wiring harness on Given car body and Prepare flatten view drawing in CATIA V5. Application of all Packaging rules, Industry best practices studied in this course shall be demonstrated in design. Apply Protection coverings as required. The first step involved in Wiring harness design process is "Input…
