Aravindan L
Mechanical Engineer Graduate | FEA | CAD | GD&T | HYPERMESH | MORPHING | SOLIDWORKS | RADIOSS | FEM | CAE | CRASHWORTHINESS ANALYSIS | 2D & 3D MESHING | ANALYST|
Skills Acquired at Skill-Lync :
- HYPER-MESH
- STRUCTURAL-MESHING
- SHEET-METAL-MESHING
- FEA
- RADIOSS
- CRASH-WORTHINESS
- CFD
- ANSYS-FLUENT
Introduction
7 Projects
Create the 1D elements on the following component with given cross-section and DOF (HYPERMESH)
OBJECTIVE : TO Create 1D elements on the following component with given cross-section and DOF a. Rod element:- with only translational DOF and RBE2 link Cross-Section: BOX- Dimension a= 12 mm dimension b=10 mm…
03 Sep 2020 02:15 PM IST
Mesh the component by using the given quality criteria in Hypermesh and assign the given thickness
OBJECTIVE: To Mesh the component by using the given quality criteria below and assign thickness. S.N Quality Criteria Value 1 Aspect Ratio 5 2 Skewness 45 3 Warping 15 4 Taper 0.5 5 Min. Length 2mm 6 Max. Length 8mm 7 Min angle Quad 45 8 Max angle Quad 135 9 Min angle Tria 20 10 Max…
03 Sep 2020 02:13 PM IST
Creating tetramesh for Chassis, Crank and Housing Model as per the given criteria in Hypermesh
OBJECTIVE: 1. To create the tetramesh for housing model using the criteria given below Target Element Size: 5mm Mini element size: 2mm Max element size: 7mm Tet collapse: 0.15 2. To create tetramesh for chassis and crank housing using the criteria given below. Target Element Size: 6mm Mini element size: 2mm Max element…
03 Sep 2020 02:22 PM IST
To Create connector in Hypermesh and Attach the various parts of the given model
OBJECTIVE: Create connector and Attach the various parts of the given model 1. Right_Rail_2 & Front_truss_1:- Seam-Quad(angled+capped+L) 2. Left_Rail_2 & Front_truss_1:- Quad elements 3. Front_truss_2, Front_truss_1 & Right_Rail_1:- Spot weld with 3 Layers and 5…
03 Sep 2020 02:07 PM IST
Preprocessing of side door panel of a plastic component in a car using Hypermesh
OBJECTIVE: To Mesh the component by using the given quality criteria below and assign thickness. Target Element Length = 4mm S.N Quality Criteria Value 1 Aspect Ratio 5 2 Skewness 45 3 Warping 15 4 Taper 0.5 5 Min. Length 2mm 6 Max. Length 6mm 7 Min angle Quad 45 8 Max angle Quad 135…
03 Sep 2020 02:23 PM IST
To Cleanup the given geometries and extract the midsurface of the components and assign proper thickness, by creating a generic property in Hypermesh
OBJECTIVE: To Cleanup the given geometries and extract the midsurface of the components and assign proper thickness, by creating a generic property.Target element length: 5mmMinimum element length: 3.5mmMaximum element length: 7mm PROCEDURE: Part 01 1. First of all, go to Import Solver Deck > import Geometry > Choose…
03 Sep 2020 02:07 PM IST
To calculate the Speed of the sound, Shock wave propagation and 3D meshing of tetra and hexa mesh in Radioss Profile
OBJECTIVE: 1. Check the material properties of the rail component and calculate the speed of sound in steel rail using the given 000.rad file 2. The length of the rail is about 1000 mm.calculate the time takes for a shock wave to travel from one end of the rail to the other. 3.Time for sound to travel the length of…
03 Sep 2020 02:08 PM IST
2 Course Certificates
HyperMesh for FEA Plastic and Sheet Metal Applications
Academic Qualification
12th
arvm
11 Nov 2020 - 09 Nov 2022
10th
ASRVM
11 Nov 2010 - 02 Nov 2022
B.E
arvm
08 Nov 2012 - 09 Nov 2016
Here are the courses that I have enrolled
