Multi cell Battery Pack

Create a MATLAB model of electric car which uses a battery and a DC motor. Choose suitable blocks from the Powertrain block set. Prepare a report about your model including following: Objectives:  System level configuration & Model parameters Results Conclusion System level configuration & Model…

OBJECTIVE-1: 1. Tag the requirements to the simulink model; tagging requirement 1 & requirement 2 to their corresponding subsystems is        fine. 2. Development of MATLAB Simulink model as per requirement.   Requirement Tagging: The requirement tagging has been attached. Then the requirement…

  Carry out a system-level simulation of an all-terrain vehicle.  Download the model from the given link:  https://www.mathworks.com/matlabcentral/fileexchange/70576-baja-all-terrain-vehicle-atv-model Prepare a technical report explaining the model properties & comments on the results. The diagrammatic …

1.Implement control logic of a “washing machine” using Stateflow as per given sequence:    If the power supply is available, the system gets activated  If the Water supply is not available, stop the process & indicate through LED Soaking time should be 200s followed by Washing time of 100s.…

Use ADVISOR tool and simulate the following      For EV_defaults_in file, if cargo mass is 500 kg with all other default conditions, can the vehicle travel for 45 km with FTP drive cycle? Conclude your observations.     In the above case, try changing the battery capacity and repeat the simulation.…

OBJECTIVE-1 : To find  the difference between mapped and dynamic model of engine, motor and generator ?   Mapped model: Dynamic model: The mapped model works with the available mapped  data (torque,speed, power) of the motor , generator and engine. Works with the lookup table data No Need of controllers…

OBJECTIVE -1: To  find out  types of power converter circuits are employed in electric and hybrid electric vehicles?  The types of power converters used in EV/HEV are  Inverter(DC-AC) Rectifier(AC-DC) Chopper(DC-DC) Regulator(AC-AC) DC-AC CONVERTER(inverter) The inverter which converts the DC-AC power…

OBJECTIVE-1: To modify the model  ‘Speed control of a DC motor using BJT H-bridge’ such that armature current doesn’t shoot up when the motor changes direction from forward to reverse.   The armature starting current of the DC motor can be changed by 4 methods PWM Armature  control Field…

  OBJECTIVE-1: To calculate the energy required for braking for a duty cycle. The user defined drive cycle for the 100s is created and attached with the script file also calculated the braking energy needed for the duty cycle. In the m file  the instantaneous brake energy of the duty cycle is calculation and …

OBJECTIVE-1: To explain, list out the total weight of various types of aircrafts.    The various types of aircraft are: The above picture shows the various types of aircraft let’s see the weight of the aircraft one by one LIGHTER THAN AIR:   Aircraft category gross weight picture Airship 10,000…

OBJECTIVE-1: To Prepare a table that includes materials & chemical reactions occurring at the anode and cathode of LCO, LMO, NCA, NMC, LFP, and LTO type of lithium-ion cells.   LITHIUM-ION BATTERY: Lithium-ion batteries are batteries that function based on the transfer of lithium ions between a cathode and an…

 Simulate generic battery model to charge & discharge using UDDS data.   SIMULINK MODEL : Simulink file https://drive.google.com/file/d/1vLIxCS0DpHAuOjMa9mXXRzNwtfbgeuTR/view?usp=sharing   WORKING & STEPS INVOLVED: The above model shows the battery discharge using the UDDS drive cycle.  In this…

To Make a MATLAB model of fuel cell-powered electric vehicle and comment on results Fuel cell-powered electric vehicle : The common type of PEMFC is mostly used in the HEV. Fuel cell vehicles produce electricity using a fuel cell-powered by hydrogen, rather than drawing electricity from only a battery. The fuel cell stack…

OBJECTIVE-1: What is coulomb counting?    It is one of the methods in the estimation of SOC. The Coulomb counting method measures the charge & discharge current of a battery and integrates the charging & discharging current over time, to estimate SOC. `SOC(t)=SOC(t0)-int((n(t)*I(t))/(Qn))*dt` Qn…

  OBJECTIVE-1: How does the weakest cell limit the usable capacity of the battery pack? The weakest cell limits the usable capacity of the battery pack. This is due to the fact that any capacity mismatch between cells and SOC levels in a series connection of cells results in a reduction of overall pack capacity. Cell…

OBJECTIVE-1: To Prepare a report summarizing thermal management techniques for electric car battery packs.   Need of thermal management: The battery pack & battery safety, performance of both power and capacity and lifespan is determined by the temperature, where the temperature is controlled and there is no risk…

OBJECTIVE-1: To simulate the thermal effects for a 10 cell series lithium ion battery model. Working: The above model shows the simulation of the thermal effect of 10 cells connected series in the circuit. The cells used here are each 50Ah with the total capacity of 500Ah battery is formed by connecting 10 batteries in…

OBJECTIVE-1: Prepare a detailed battery pack along with its drawing. State your assumptions.   ASSUMPTION DATA: Battery pack capacity: 18 kWh,  Cell: ANR26650M1-B.  Datasheet Reference link https://drive.google.com/file/d/18F2QPjldeIpYehuhDBmAa4glsRzb9E-n/view?usp=sharing Single-cell estimation: Voltage…
