Fender Design Challenge

FENDER DESIGN

- FENDER IS A PART OF AN AUTOMOBILE THAT FRAMES A WHEEL WELL.

- ITS PRIMARY PURPOSE IS TO PRESENT SAND , MUD , ROCKS , LIQUIDS & OTHER ROAD SPRAY FROM BEING THROWN INTO AIR BY ROTATING TYRE.

- WHEN VEHICLE IS MOVING TYRES PICK UP STONES AND HURT THEM IN ALL DIRECTIONS , FENDERS ARE BASICALLY PRESENT TO PREVENT ANY INJURIES TO THE PEDESTRAINS AND CONTAIN MOTION

OF THESE PARTICLES.

MOUNTING'S IN FENDER :

THERE ARE FIVE MOUNTING IN AN FENDER

- BODY

- A PILLAR

- SILL

- COWL TOP

- DRIP AREA

DESIGN CONSIDERATIONS FOR FENDER :

- THE MOST IMPORTANT CONSIDERATION WHILE DESIGNING A FENDER IS DRIP AREA , WHEEL ARCH AREA AND OTHER REMAINING AREAS OF MOUNTING.

DRIP AREA :

- DRIP AREA IS THE MOUNT FROM WHICH FENDER IS ATTACHED TO THE COMPARTMENT.

- THERE ARE FEW DIMENSIONS GIVEN WHILE DESIGNING DRIP AREA OF FENDER FIRST FOR THE COWL TOP ASSEMBLY THAN FOR THE HEADLIGHT UNIT AND ALSO ENGINE COMPARTMENT

A PILLAR ETC.

- WE CAN EVERY WELL SEE IN THE MASTER SECTION PROVIDED TO US.

WHEEL ARCH AREA :

- THE SEMI CIRCULAR AREA OR CUT SECTION FOR THE WHEEL IS KNOWN AS WHEEL ARCH AREA.

- THERE ARE DIIFERENT METHODS FOR WHEEL ARCH CONSIDERATION THAT WE SAW IN PREVIOUS CHALLENGE.

BUMPER MOUNTING AREA :

- A MOUNTING PROVIDED TO ATTACH BUMPER WITH FENDER.

FENDER LINING MOUNTING :

- A MOUNTING PROVIDED TO MOUNT THE FENDER LINING.

A PILLAR MOUNTING :

- A MOUNTING PROVIDED TO MOUNT A PILLAR OF THE VEHICLE.

SILL MOUNTING :
