Advanced Sheet Metal Design Using NX Cad Challenge_6_Bracket

Procedure

• Create a sketch and make it as a conture flange
• After the contour flange obtained create a sketch on the top of the body
• After the sketch create, now using normal cut, cut the path of sketch
• Now breake the corners to create a smooth edge
• The bend the sheet and sketch a line
• Create a bead on the sheet
• Rebend and create holes

Conclusion

Hence a Bracket is desgined using NX 11
