Week 8 - Challenge 1 - Base Bracket Design

Report :

1) Received Class A surface.

2) Created tooling axis using bisect method.

3) Splitting complete surface into 3 profiles.

4) Created offset for ribs.

5) Created B surface.

6) Created outer boundary, created sweep using draft direction.

7) Repeated the process for holes.

8) Joined C surface with A surface, then trimmed it with B surface.

9) Created Closed body.
