RT instability is the instability of an interface between two fluids of different densities which occurs when the lighter fluid is pushing the heavier fluid .water suspended atop oil is an everyday example of Rayleigh Taylor and it may be modeled by two completely plane-parallel layers of immiscible fluid the denser on…
