Week 3 - 2D meshing for sheet metal
Aim- To clear topological and cad error, extract midsurface and mesh the component according to quality criteria.
Procedure-
1. First we individually do topo on every component.
2. Then we do geometry checks from tools and do auto fix.
3. Then we create midsurface by skin option
4. Then before jumping onto mesh we do proper cuts on the model for better mesh flow and assign mesh parameters and quality criteria.
5. Then we do mesh and reconsturct according to needs to organise mesh flow, use splits, paste, align etc.
6. Most of the models are symetrical, so transform option is used create final mesh model.
Please click on this link for the file: https://drive.google.com/file/d/1y_lH1iiNQ1TcaVzFYxBIRujomG4sxlcG/view?usp=sharing
