Underbody Coating

UNDER-BODY COATING:

Vehicle's underside serves as an intermediate between metal components of a vehicle and outer environment. Underbody of vehicles is prone to damage due to harsh environmental conditions. Coatings are applied to the underside of the vehicles to protect them against factors such as corrosion, chemicals, moisture, water damage, and chipping of the underbody,. Automotive underbody coatings offers a protective layer to vehicle's underside. Most of these coatings provide chemical and corrosion resistance, along with several other properties based on different product formulations. Protection of underbody and wheel arches against chip damage is achieved by applying automotive underbody coatings, which protect the metal from debris of gravel, stones, salts etc. tossed by the road.

Coating process of vehicle body (automotive coating process) comprises minimum five layers of paint, while the underbody coating processs comprises the forst two layers in the overall coating process. These two layers provide durable protection against corrosion; however, damage over time requires renewal of these coatings. Automotive aftermost service providers often provide these services during scheduled vehicle maintenance.

Automotive underbody coatings also offer protection against humidity, moisture, and wet conditions that can seep through the undercarriage of a vehicle through joints or cracks in the paintwork; and cause corrosion.

Elasticity of polymers used in automotive underbody coatings allows for low noise when struck by road debris compared to that with uncoated underbody result, vibrations of vehicles are dampened and kept to a minimum.

TYPES OF UNDERBODY COATING :

having undercoating professionally applied to your vehicle can be expensive, but fortunately, if your budget is tight, you can do it yourself for a fraction of the price. Here are some of the various types of undercoating available.

POLURETHANE UNDERCOATING :

This type of undercoating is a little bit quicker and easier to apply. oftentimes, polyurethane undercoating will come in canisters ready to preload into an application gun. This type of sealant works by seeping into all cracks and seams, dispalcing salt and moisture and oozing around rusty areas to bomd with and protect unoxidized metal. It also sands quickly in case you will need to perform bodywork and can be painted over.

On the flipside, this type of car undercoating generally requires a little bit more surface prep work before applying--sanding and applying an etching primer to bare metals before usimg are generally recommended.

RUBBERIZED UNDERCOATING :

Rubberized vehicle undercoating is easy to apply and offers sound-coushioning as well as protection from dust, moisture, and dings or dents. In addition to your undercarriage, rubberized undercoating is also safe to use on wheels wells and quarter panels, and dries to a soft rubbery finish that prevention furthur rust, damage, or moisture seeps. The coating can be painted over and, if necessary for bodywork, can be easily removed with an undercoating removal spray.

Overall, rubberized coating is generally the best option for protecting your vehicle's undercarriage, as it provides the simplest and best protective measures against rust and moisture.

WAX OR PARAFFIN-BASED UNDERCOATINGS :

A paraffin-based undercoating will be the cheapest and quickest option available with which to protect the undercarriage of your vehicle. However, keep in mind that it will wear off quicker than other types of undercoating and will need to be stripped and reapplied at least once every year.

Wax-based undercoatings never truly harden. During application, they drip or flow into seams and cracks to provide protective properties. They are usually available in a spray gun canister or in an aerosal can and offer at least a base protection in moderately humid climates.

ASPHALT-BASED UNDERCOATING :

For standard vehicles, any of the aforementioned types of undercoating will provide sufficient protection. For large trucks and heavy machinery, asphalt-based undercoating provides a bit of extra durability against rocks, chips, and moisture.

Asphalt-based undercoating generally contains a little bit of rubberized material that sets up firmly and also helps soften noise. Generally sold in five gallon containers, this type of undercoating also needs more cure time than the other three, and is not paintable, making it best to use only for undercarriages.

Advantages of Underbody Coating :

1. Undercoating gives an extra layer if protection against rust and corrosion, protecting your car.
2. Undercoating will eventually wear out, but you can get years of protection from it. Even vehicles in warmer climates gain peotection as debris is repelled and kept away from eating at the vehicle.
3. It can be self-applied.
4. It minimizes the sound from underneath the car.
5. It insulates the interior of the car from the extreme temperature from beneath the vehicle.
6. The coating does not chip away when hit by stones.

Disadvantages of Underbody coating :

1. Undercoating will not help you if corrosion already exists and the corrosion needs to be removed first before it can be applied, which can be expensive for you.
2. It adds weight to the vehicle.
3. It must be reapplied every 3 to 5 years for the best results.
