Drafting of various geometries using Chamfer, Fillet tool in AutoCad

AIM : To create the drafting of various geometrics using Champer,fillet tool by using AUTOCAD.

PROICEDURE :

Q-1 : UNIT USED IS DECIMAL :-

• In this drawing we create a simple drawing.
• Now we can see the command used for drawing as step by step.

Steps :

1. First check the dimensions as we start before a line.
2. Next start with a "L" line command.
3. Draw a line as per dimensions mentioned.
4. For angle lines press '<' and type a angle.
5. click C for circle command to draw.
6. press " Diameter or radius " to creatye a circle.
7. After completing a drawing we need to show dimention of every objects foir this , click " DIM " command to show dimension.
8. For to measure angle between two lines click " DIMANG ".
9. Click " DIMDIA " command to measure the diameter of circle.
10. Use a snipping tool to take a screen shot after once dimensioning and texting is done ( use " TEXT " COMAMND to texting ).
11. Finally click Save as to save picture.

Q-2 : UNIT USED IS ARCHITECTURAL DRAWING :-

• In this drawing we create a simple drawing.
• Now we can see the command used for drawing as step by step.

Steps :

1. First check the dimensions as we start before a line.
2. Next start with a "L" line command.
3. Draw a line as per dimensions mentioned.
4. For angle lines press '<' and type a angle.
5. click Units to change a Architectural 0'-0" .
6. After completing a drawing we need to show dimention of every objects foir this , click " DIM " command to show dimension.
7. For to measure angle between two lines click " DIMANG ".
8. Click " DIMDIA " command to measure the diameter of circle.
9. Use a snipping tool to take a screen shot after once dimensioning and texting is done ( use " TEXT " COMAMND to texting ).
10. Finally click Save as to save picture.

Q-3 : UNIT USED IS ENGINEERING DRAWING :-

• In this drawing we create a simple drawing.
• Now we can see the command used for drawing as step by step.

Steps :

1. First check the dimensions as we start before a line.
2. Next start with a "L" line command.
3. Draw a line as per dimensions mentioned.
4. For angle lines press '<' and type a angle.
5. click Units to change a Engineering 0'-0.0" .
6. Click " c " for circle comand to draw.
7. Press " Diameter / radius " to create circle.
8. After completing a drawing we need to show dimention of every objects foir this , click " DIM " command to show dimension.
9. For to measure angle between two lines click " DIMANG ".
10. Click " DIMDIA " command to measure the diameter of circle.
11. Use a snipping tool to take a screen shot after once dimensioning and texting is done ( use " TEXT " COMAMND to texting ).
12. Finally click Save as to save picture.

Q-4 : UNIT USED IS DECIMAL DRAWING :-

• In this drawing we create a simple drawing.
• Now we can see the command used for drawing as step by step.

Steps :

1. First check the dimensions as we start before a line.
2. Next start with a "L" line command.
3. Draw a line as per dimensions mentioned.
4. After completing a drawing we need to show dimention of every objects foir this , click " DIM " command to show dimension.
5. For to measure angle between two lines click " DIMANG ".
6. Click " DIMDIA " command to measure the diameter of circle.
7. Use a snipping tool to take a screen shot after once dimensioning and texting is done ( use " TEXT " COMAMND to texting ).
8. Finally click Save as to save picture.

Q-5 : UNIT USED IS DECIMAL DRAWING :-

• In this drawing we create a simple drawing.
• Now we can see the command used for drawing as step by step.

Steps :

1. First check the dimensions as we start before a line.
2. Next start with a "REC" Rectangle command.
3. Draw a line as per dimensions mentioned.
4. Select the midpoint to create a circele.
5. Click  " C "  for circle command to draw.
6. Press ' Diameter / radius ' to create circle.
7. Click ' MI ' command to mirror the object pick with center point.
8. After completing a drawing we need to show dimention of every objects foir this , click " DIM " command to show dimension.
9. For to measure angle between two lines click " DIMANG ".
10. Click " DIMDIA " command to measure the diameter of circle.
11. Use a snipping tool to take a screen shot after once dimensioning and texting is done ( use " TEXT " COMAMND to texting ).
12. Finally click Save as to save picture.

Q-6: UNIT USED IS DECIMAL DRAWING :-

• In this drawing we create a simple drawing.
• Now we can see the command used for drawing as step by step.

Steps :

1. First check the dimensions as we start before a line.
2. Next start with a "REC" Rectangle command.
3. Draw a line as per dimensions mentioned.
4. Select the midpoint to create a circele.
5. Click  " C "  for circle command to draw.
6. Press ' Diameter / radious ' to create circle.
7. Click ' MI ' command to mirror the object pick with center point.
8. Click ' RO ' to ratote command used to rotate the objects.
9. After completing a drawing we need to show dimention of every objects foir this , click " DIM " command to show dimension.
10. For to measure angle between two lines click " DIMANG ".
11. Click " DIMDIA " command to measure the diameter of circle.
12. Use a snipping tool to take a screen shot after once dimensioning and texting is done ( use " TEXT " COMAMND to texting ).
13. Finally click Save as to save picture.

Q-7: UNIT USED IS DECIMAL DRAWING :-

• In this drawing we create a simple drawing.
• Now we can see the command used for drawing as step by step.

Steps :

1. First check the dimensions as we start before a line.
2. Next start with a "REC" Rectangle command and ' L for line command .
3. Draw a line as per dimensions mentioned.
4. Select the midpoint to create a circele.
5. Click  " C "  for circle command to draw.
6. Press ' Diameter / radius ' to create circle.
7. Click ' ARCH '  and select 3 point arch command to draw arch .
8. Click ' MI ' command to mirror the object pick with center point.
9. Click ' RO ' to ratote command used to rotate the objects.
10. After completing a drawing we need to show dimention of every objects foir this , click " DIM " command to show dimension.
11. For to measure angle between two lines click " DIMANG ".
12. Click " DIMDIA " command to measure the diameter of circle.
13. Use a snipping tool to take a screen shot after once dimensioning and texting is done ( use " TEXT " COMAMND to texting ).
14. Finally click Save as to save picture.

Q-8: UNIT USED IS DECIMAL DRAWING :-

• In this drawing we create a simple drawing.
• Now we can see the command used for drawing as step by step.

Steps :

1. First check the dimensions as we start before a line.
2. Next start with a "C"  for circke command.
3. Click tangent to pick a point and draw.
4. Draw a line as per dimensions mentioned.
5. Select the midpoint to create a circle.
6. Press ' Diameter / radious ' to create circle.
7. Click ' ARCH '  and select 3 point arch command to draw arch .
8. Click ' MI ' command to mirror the object pick with center point.
9. Click ' RO ' to ratote command used to rotate the objects.
10. After completing a drawing we need to show dimention of every objects foir this , click " DIM " command to show dimension.
11. For to measure angle between two lines click " DIMANG ".
12. Click " DIMDIA " command to measure the diameter of circle.
13. Use a snipping tool to take a screen shot after once dimensioning and texting is done ( use " TEXT " COMAMND to texting ).
14. Finally click Save as to save picture.

Q-9: UNIT USED IS ARCHITECTURAL DRAWING :-

• In this drawing we create a simple drawing.
• Now we can see the command used for drawing as step by step.

Steps :

1. First check the dimensions as we start before a line.
2. Next start with a "C"  for circke command.
3. Click tangent to pick a point and draw.
4. Draw a line as per dimensions mentioned.
5. Select the midpoint to create a circle.
6. Press ' Diameter / radious ' to create circle.
7. Click ' O ' to offset the object as per dimension mentioned.
8. Click ' TRIM ' command to trim the object.
9. After completing a drawing we need to show dimention of every objects foir this , click " DIM " command to show dimension.
10. For to measure angle between two lines click " DIMRAD " abd " DIMDIA " to measure radius of circle.
11. Click " DIMDIA " command to measure the diameter of circle.
12. Use a snipping tool to take a screen shot after once dimensioning and texting is done ( use " TEXT " COMAMND to texting ).
13. Finally click Save as to save picture.

Q-10: UNIT USED IS DECIMAL DRAWING :-

• In this drawing we create a simple drawing.
• Now we can see the command used for drawing as step by step.

Steps :

1. First check the dimensions as we start before a line.
2. Next start with a "REC"  for Rectangle command.
3. Click ' pol ' to pick a point and draw polygon .
4. And create a 4 point to outer the rectangle.
5. Draw a line as per dimensions mentioned.
6. After completing a drawing we need to show dimention of every objects foir this , click " DIM " command to show dimension.
7. Use a snipping tool to take a screen shot after once dimensioning and texting is done ( use " TEXT " COMAMND to texting ).
8. Finally click Save as to save picture.

Q-11 : UNIT USED IS DECIMAL DRAWING :-

• In this drawing we create a simple drawing.
• Now we can see the command used for drawing as step by step.

Steps :

1. First check the dimensions as we start before a line.
2. Click ' UNITS ' to change a Architectural 0'-0" .
3. Next start with  ' L  ' for line command .
4. Draw a line as per dimensions mentioned.
5. Ans for angle line press ' < ' and type angle measurement.
6. Click ' MI ' command to mirror the object pick with center point.
7. Click ' POL' to create a polygon and pick a 4 points and draw.
8. After completing a drawing we need to show dimention of every objects foir this , click " DIM " command to show dimension.
9. For to measure angle between two lines click " DIMANG ".
10. Click " DIMDIA " command to measure the diameter of circle.
11. Use a snipping tool to take a screen shot after once dimensioning and texting is done ( use " TEXT " COMAMND to texting ).
12. Finally click Save as to save picture.

RESULTS : created geometries figure are shown in above images.
