Week 3 - 2D meshing for Sheet metal

https://drive.google.com/file/d/1gLKBSF6Mh389zCcgB1sB4AOUFWmIHe8P/view?usp=sharing     AIM: - To create volumatric mesh given model on different target length of part. Part is shown in below figure Procedure: -   To clean model like delete over lap surface and extra extuded surface. as shown in figure…

 AIM: - To topology cleanup for the given model and check geometry cleanupand set three different target lengths as three different cases for mesh the model.    Procedure: - The model given shown in figure to clean model like fill hole or create new surface.    Select new option for create…

Detail: - To create valid connection. TYPE OF CONNECTION : -  Bolt connection  RBE 2 RBE2 two node spot weld  spot line  All connection shoen in figure in below.

Objective: - To create mid surface and good mesh flow. Procedure: - Geometry Clean-up use tool like release cons and delete extra hot point Remove single cons in given cad model and after that topo.  After that create auto mid surface generation have used method skin option in mid surface and offset method…

Objective: - To create the mid surface, and mesh with element Quality criteria.  Cad model   Procedure: -  Geometry Clean-up use tool like release cons and delete extra hot point Remove single cons in given cad model and after that topo. Mid Surface: -  For mid surface generation have used method skin…

Aim: - TO create tria and ortho tria element method on surface after that convert to volume mesh and check tet collapse error. Procedure: - Import CAD model after that topo and do check geometry. Before topo- After topo and geometry clean up- four-part present in this challenge    after that tria…

Objective:- To generate mid surface of cad model and meshing according to given criteria. S.No  Quality Criteria  Value  1 Target/Average length   5 2 Minimum Length  2 3 Maximum Length  7 4 Aspect  3 5 Warpage 15 6 Skewness 45 7 Jacobian  0.7 8 Minimum Quad Angle  45 9 Maximum Quad Angle  135 10 Minimum  Tria Angle  30…
