Vehicle Ride 2
| PARAMETER | FRONT SUSPENSION | REAR SUSPENSION |
| SPRUNG MASS CRITICAL DAMPING | 265.9713 | 291.8573 |
| UNPRUNG MASS CRITICAL DAMPING | 311.7691 | 259.2296 |
| SPRUNG MASS INITIAL DAMPING COEFFCIENT | 186.1799 | 204.2976 |
| UNSPRUNG MASS INITIAL DAMPING COEFFCIENT | 62.3538 | 51.8459 |
| LOW SPEED COMPRESSION DAMPING COEFFECIENT | 96.7419 | 108.1041 |
| HIGH SPEED COMPRESSION DAMPING COEFFECIENT | 8.4853 | 8.4853 |
| LOW SPEED REBOUND DAMPING COEFFECIENT | 290.2258 | 324.3123 |
| HIGH SPEED REBOUND DAMPING COEFFECIENT | 25.4558 | 25.4558 |
Attached below is the link containing the MATLAB CODE containing all the calculations involved in the problem statement:
https://drive.google.com/file/d/1xINoHZpsVoljHTIfd6_rO5cG8ywzMlJ4/view?usp=sharing
