Project 2_Creating a 3D rendered model for a Residential Building in AutoCad

Aim:

To create a 3D rendered model for a Residential Building.

Prepare:

• Using Rectangle Command, draw the rooms
• Offset for the walls
• Using Layer command give the colors
• Using Library add the assets and furniture for the required rooms
• Place the windows and doors as required
• Extrude the walls
• Give the desired materials and hatches
• Using 3ds max give realistic shades

Result:

Ground Floor:

FirstFloor:

3D renders:

GroundFloor

First Floor:
