Project 2_Creating a 3D rendered model for a Residential Building in AutoCad

Aim - To create a rendered view of residential building

Procedure-

Open a 3d basics in settings window

The draw a plan in 2d

Create a region using boundary command and select the regions of walls and windows

Then go to isometric view

Then give layers to all walls,windows,doors,slab and walls and give colours to them

Use extrude command and extrude the walls to 10'

Then extrude the windows from top and bottom by shofting UCS

Join them by using UNION command

Draw the slabs and extruse to 150mm

Set different views

Set cameras and views

Then start rendering using RR command
