Advanced Sheet Metal Design Using NX Cad Challenge_6_Bracket
Modeling and Drafting Bracket using NX CAD
OBJECTIVE:
To model an L-shaped bracket with given 2-D input.
INTRODUCTION:
Sheet metal Brackets have a range of applications within the industry. counting on the appliance and dealing conditions different materials are often accustomed create brackets. like Titanium, Aluminum, SS, plastic material, Ceramic, etc. during this project, we are going to model a straightforward L-shaped bracket using the given 2-D data.
DESCRIPTION:
- Sketch - sketch a top level view of contour flange feature with dimensions from a front view,
- Contour Flange- it'll extrude the outline of the sketch along a vector the thickness of the flat solid is initially provided
- Normal cutout - Normal cutout is employed to get rid of the surplus material from the part and supply the specified geometric part.
- Break comer - Break comer is employed to supply a fillet type faster to the sharp corners of the sheet it's accustomed provide safety as well on relieve stress concentration.
- Bead - Bead feature will provide stiffness to the bracket the peak of the feature is kept per DFM guidelines.
- Hole-hole command is employed to produce mounting holes for the bracket all the holes have a size of M18 with a fit of H13.the gap from the sting is additionally in keeping with DFM standards.
