Pre Engineered Building Design in STAAD PRO

Held 24 Mar 20212 videos

Notes written by Skill-Lync from the recording · Updated 17 Nov 2026

What this workshop covers

This recorded workshop walks through pre-engineered building (PEB) design in STAAD.Pro, from components and Indian codes to loads, modelling and connections. In part 1 the instructor explains what makes a PEB different from a conventional steel shed: built-up I-sections cut from plate and welded, tapered so members are deep where moments are high and shallow where they are low, and frames bolted together on site. He covers the advantages claimed for PEBs, the primary and secondary members (main frames, gable frames, purlins, girts, eave struts, bracing), bay spacing and clear height, and the Indian standards used: IS 800, IS 875, IS 1893, IS 801, IS 811, IS 2062 and IS 4923.

Part 2 moves into STAAD.Pro: the client inputs to collect, modelling the frame with tapered sections, bracing and supports, converting sheeting and purlin weights into rafter loads, wind load per IS 875 Part 3, seismic input per IS 1893, and the IS 800 design parameters used to check members, followed by a quick look at end-plate, splice and base-plate connections.

It suits civil and structural engineers who already know basic STAAD.Pro. This is a Skill-Lync session from March 2021 and it is an overview: purlin, girt and connection design are done in spreadsheets and are not worked through, and only Indian codes are used.

Chapters

Part 1

  1. 0:07 PEB market size and where PEBs are used
  2. 2:39 Roles in the PEB industry and major PEB companies
  3. 3:20 What a pre-engineered building is
  4. 5:40 Tapered frames vs conventional hot-rolled frames
  5. 8:31 Advantages: weight, build time, quality, clear spans
  6. 12:21 PEB components: main frame, gable frame, purlins, girts
  7. 14:40 Bay spacing, end posts, clear height and eave height
  8. 17:24 Indian codes: IS 800, IS 875, IS 1893, IS 801, IS 811
  9. 20:33 Load types: dead, live and collateral loads

Part 2

  1. 0:06 Wind and seismic loads, IS 800 load combinations
  2. 1:17 Client inputs to collect before designing a PEB
  3. 3:02 Reading the architectural plan, main and gable frames
  4. 4:21 Modelling the frame and tapered sections in STAAD.Pro
  5. 6:44 Bracing as tension members, pinned vs fixed bases
  6. 7:53 Seismic definition and dead and live loads as UDLs
  7. 10:23 Wind load factors per IS 875 Part 3
  8. 12:04 STAAD.Pro design parameters for IS 800 member checks
  9. 16:51 Tapering by trial, deflection checks, typical connections

Key points from the session

  • Start every tapered rafter and column as a uniform section, run the analysis, then reshape the depths to follow the bending moment diagram, iterating until every unity ratio is below 1.0. The instructor's first guess is a 5 mm web, 12 mm flanges and about 500 mm depth.
  • Keep bay spacing to about 8 m or less. Beyond that the purlins and girts spanning between frames get heavy and the building stops being economical, while much closer spacing adds frames and also costs more.
  • Purlins and girts are cold-formed sections designed to IS 801, with section properties from IS 811. STAAD.Pro does not design them, so they are sized in validated spreadsheets and their weight is applied to the rafters as a uniformly distributed load.
  • In the worked example, roof sheeting is taken as 5 kg/m2, a self-weight factor of 1.15 covers connections that are not modelled, and the roof dead load totals about 20 kg/m2 before it is multiplied by the bay spacing. Live load on an inaccessible roof is 0.75 kN/m2.
  • Wind or earthquake load usually governs because PEBs are light. Wind follows IS 875 Part 3 with k1, k2, k3 and the newer directionality, area-averaging and combination factors (Kd, Ka, Kc); the seismic example uses a zone factor of 0.16 for Chennai per IS 1893.
  • In the STAAD.Pro IS 800 design block, set FYLD to the actual steel grade (the example changes the 250 MPa default to 350 MPa), set STP to 2 for welded built-up sections, define effective lengths instead of accepting node-to-node defaults, and use TRACK 2 to see why a member fails.
  • Pinned bases usually give lighter columns because little moment reaches the base; switch to fixed bases if lateral deflection becomes excessive. Bracing is specified as tension-only, and the instructor suggests at least one braced bay in roughly every five bays.

What is a pre-engineered building?

A pre-engineered building is a steel building whose columns and rafters are built-up I-sections, cut from plate on CNC machines and welded in a factory, then shipped to site and bolted together. The instructor compares it to flat-pack furniture. Members are tapered to match the forces, which is why PEBs use less steel than conventional sheds.

Why is a PEB lighter and faster to build than a conventional steel building?

The instructor credits tapered welded sections that remove steel where bending is low, and thin cold-formed purlins and girts, which he says make up 30-40% of the building weight. He cites PEBs as up to 30% lighter and quotes 6-8 weeks for delivery against 22-28 weeks for site-fabricated conventional steel.

Does STAAD.Pro design the purlins, girts and connections of a PEB?

Not in this workflow. STAAD.Pro models the building and checks the primary frames and bracing to IS 800. Purlins and girts are analysed as continuous beams in validated spreadsheets to IS 801, and base plates, end plates and splices are designed in spreadsheets from the member forces STAAD.Pro reports.
