Week 9-Creation of 1D Connectors Challenge

OBJECTIVE:

To create and explore all kinds of connectorts in hypermesh,so that we can create connecters for the given model.

CAD MODEL:

WORKING PROCEDURE:

• For the given model their are different connectorts should be used at different places so that first should create a mesh

• Then create the connectorts using 2D- connecters ,then select the sutiable type of connector for the following gap in the model.

• Select the line list then the compents the connecter should connect then click create to create the coonector inbetween the gaps.

• For bolt we should only select only two nodes of component and should select the components to connect and click create.

• The rest of the gaps can be connected with any other tyes of connceters.

RESULT:

Connecters has been created for the given model for the required places using hypermesh.
