Week 8 - Challenge 6 - Core & Cavity Design

REPORT:-

1. TOOLING AXIS

Here we create the tooling axis on the base plan, Intially create point the plane and place the axis system on the point ,create 2 dummy tooling axis on the plan,

For the first dummy tooling axis create the bisecting line with reference to two line which are create on the intersecting line

For the second dummy tooling axis thire get reference line on one side only so we create tooling axis by giving the draft angle between them.

create the final tooling axis line by bisecting the these two dummy line.
