Week - 4

AIM:-     Design an MPPT controller with Boost to meet the following specifications and obtain the simulation results. PV output voltage/ Input voltage of converter=250-350V Output voltage= 600V Rated PV power =100kW Switching frequency=5kHz Current ripple=5% Voltage ripple=1% Repeat the above using a two-stage Interleaved…

AIM:-       Design a DC-DC SEPIC converter with input voltage = 10 V, output voltage = 0-20V Take  f = 50 kHz, ΔI1=ΔI2 =0.2 A, , Δv1=Δv2 =0.2V. Find the state space model of the converter Construct the converter in MATLAB and simulate  Obtain the waveforms for input and output voltage, inductor current and capacitor voltage…

AIM:-       Design a DC power supply using PFC circuit for general purpose applications with 350V dc output and load in the range of 0-7A. The supply should meet the harmonic standard limits for input power quality such that current THD limits are satisfied with input power factor >0.97 value. The input…

AIM:-      Creating a workspace for WiFi module in altium Defining a PCB board size using the DXF data provided PCB clearance to be set as 0.15mm and track width to be 0.2mm for power line and 0.15mm for rest of the circuit Following the image and BOM provided for creating the schematic and find the datasheet from online…

AIM:-         Creating a workspace for Ethernet shield in altium Defining a PCB board size using the DXF data provided PCB clearance to be set as 0.15mm and track width to be 0.2mm for power line and 0.15mm for rest of the circuit Following the image and BOM provided for creating the schematic and find the datasheet from…

AIM:-     Problem statements: Part A: The three-phase diode rectifier is supplying approximately 2.2 kW load with VLL=208V at 60 Hz, Ls=1 mH and Cd=1100 μF, where Cd is the DC side capacitor. Design the circuit in one of the simulation platforms (MATLAB or Ltspice/Simetrix) and obtain the circuit waveforms. Based on their…

AIM:-     Model 3 Phase Inverter using Simulink (model the parasitic as well) with a switching frequency of 10Khz using 3 phase Squirrel Cage Induction motor, using V/F method, open loop Design Parameters: Power = 100 HP DC Voltage = 800 V Output Voltage = 460 VRMS – line to line Initial Speed = 1500 RPM Final Speed =…

AIM:-        Extending the learned lessons in previous module, you will be diving into another power electronics concept on your own. Design of boost converter, and calculating the loss of different components including power switching device and deriving efficiency of boost converter. This is applicable…

AIM:-       Design an interleaving DC/DC converter system for a data centre application with the following specifications: • Input voltage: 45 – 60 v• Output voltage: 3 V• Output current: 100A• Efficiency > 85% (extra credit for efficiency higher than 90% on a spice-based software…

AIM:-                 1.        BUCK CONVERTER          Given,         Vin=40-50v         Vout=30v         power=500w Schematic diagram of buck convereter:              Observations and calculations:                                                                                                                 Simulink…

Aim:-           To study,analyze and make a detailed report on BAJAJ ALL TERRAIN VEHICLE (ATV) using simulink   Objective:-           Prepare a technical report explaining the model and properties and comment on the result Introductions:- ALL TERRAIN…

1.        Aim:-                   Implement control logic of a “washing machine” using Stateflow as per given sequence:  If the power supply is available, the system gets activated  If the Water supply is not available, stop the process…

1.     Aim:-             make a simulimk model of a doorbell using solenoid block.     Basic simulink model used:-              1.puls generator:-                 (used to create a square wave pulse at regular intervals.)                                                                                  2.switch block:-…
