3-2-1 PRINCIPLE

The 3-2-1 principle is a work-holding principle where three pins are located on the 1st principle plane, i.e., either XY, YZ, ZX. And two pins are located on the 2nd plane perpendicular to the 1st plane, and at last, one pin on the plane is mutually perpendicular to the 1st and 2nd planes. This method is often used in woodworking when making mortise and tenon joints.

The name comes from the order of operations: first you cut your piece of material to length, then width, then thickness (thickness being the last step). This allows for easy reference as one works through a task. The 3-2-1 method can be applied to any number of tasks in all areas of life where assembly is required.

It is also common practice to use this method when cutting a workpiece to length. In this case, the 3-2-1 method refers to the order of operations for making a straight cut: first establish the desired length; then set the stop and lock it in place (the second step); then unplug the machine and begin moving the blade up and down (the third step); and finally make the final cut (the fourth and last step).

The Locating Process: Degrees of Freedom

In order to completely specify the position in space of a three-dimensional

object (such as the cube that’s shown), we refer to six coordinates:

1. Translational position along the X-axis
2. Translational position along the Y-axis
3. Translational position along the Z-axis
4. Rotational position about the X-axis
5. Rotational position about the Y-axis
6. Rotational position about the Z-axis

These six coordinates are known as the six degrees of freedom of a three-dimensional object. As the double-headed arrows indicate, the translational and rotational positions can vary in either direction with respect to each of the three axes.

To completely prevent movement, all six degrees of freedom must be restricted.

The Locating Process: 3-2-1 Method

We have two objectives when mounting a part in a fixture for machining:

1. Accurately position the part at the desired coordinates.
2. Restrict all six degrees of freedom so that the part cannot move.

A widely used method of accomplishing these two objectives uses the 3-2-1 principle, so-called because it entails three steps that employ three, then two, then one fixed points of known location. Since that adds up to six fixed points, it’s also known as the six point method.

In the three steps of the 3-2-1 method, three mutually perpendicular planes, called datum planes, are introduced, one at each step. These three planes define the workpiece position, and together with opposing clamping forces fully constrain the part.

-

What is 3-2-1 Principle?

A fundamental concern in metalworking is locating the part to be machined, punched, bent, or stamped relative to the work platform (fixture). For example, a CNC machine tool starts its process at a specific point relative to the fixture and proceeds from there. Hence, the accuracy with which a part is machined is quite dependent on the accuracy with which it is positioned in the fixture. Accurate locating of not just one part, but each and every part that is loaded into the fixture is crucial. Any variation in part location on the fixture adds to the dimensional tolerance that must be assigned to the finished parts.

Additionally, the method of supporting and securing the part in the fixture affects not only dimensional tolerances, but surface finishes as well. This is true because improper supporting or clamping can temporarily or permanently deform the part. Hence, techniques for supporting and clamping must be considered together with the method of locating in order to assure repeatability from part-to-part.

- - -
