Project - Analysis of a practical automotive wiring circuit

Answer:-     The figure above is the Backdoor of a car for which a Wiring Harness has to be designed A wiring harness will be done for the taillights and the no plate lights There are 2 4pin Taillight connectors and 2 2pin for the no plate lights and a 12-pin Inline connector The inline connector that will connect it to…

AIM- Routing for side door panel Route the wire for the side door of a care with the necessary connector along with the guiding challenge data given  TASK  Routing assembly creation  Flattening  Drawing creation  A door wiring harness is a device made of insulating material, such as rubber or vinyl, to enclose wires in…

DEFINIG ELECTRIC PARAMETER FLOW CHART:- CONNECTOR DEFINATIONS IN CATIA V5 1. Deutsch DT06 – 08SA Connector connection point:   Create midpoint on the contact face which will be normal to wire bunddle insertion. Craete Axis System with respect to the point which we have created and defining the axis direction…

Process - 1.) Define the Connector a) Download Connector 3D Part from www.te.com DT06-4S b) Create a Required Geomtrical parameters- Point, Axis Systems   c) Define Part as a connector   Switch from part workbench to Electrical Part workbench, Using the Define connector command to define the connector as a Electrical component…

In the diagram above, the electrical connectors are represented by numbers:- 1. There are different types of connectors in ten different places.2. Bundle continuity for the two created harnesses must be checked.3. Once the two Harnesses have been created, the next step is to connect them electrically.4. Examine Harness…

Answer1:- p-clamp:- Create a point for entry plane:- Create a point for exit plane:- Creating plane:- Create base plane:- Define as electrical support Switch in to electrical part design Click define support and click the clip Entry, exit and base of the clip are defined    There are two entries and two exists are available…

Title: Defining Connectors and Clips using CATIA V5 Objective : Downloading the 3D CAD files form the te.com website and then defining the parts electrically and further creating a catalogue for the components. Introduction:  A connector is a device(or more precisely, a mating pair of devices, often a plug and a socket)…

Description:- The development of a forward energy-based fuel consumption model of a P1 hybrid vehicle. This model is based on the conventional vehicle model from Project 1. The main goal of this project is to understand the functionality of a P1 hybrid and be able to model it. Honda Insight motor and battery are considered…

THEORICITAL CONCEPTS REGARDING FORWARD ENERGY MODEL OF CONVENTIONAL VEHICLE: A driver controller is required to control the vehicle to follow a desired speed and set the start of the calculations. The controller is implemented to model the driver that will either push the accelerator or the brake pedal to match the desired…

Ans:- The Transfer function for spring mass damper system is  X(s)/F(s)=1/ms^2+cs+k where X(s) is displacement of the position wrt the force acting on the mass. F(s) is the force applied on the mass.m is mass=3.6kg, c=damping constant=100Ns/m, Spring constant=400 N/m. To control the displaced position of the mass after…

Project:-  Interpolation is a method of fitting the data points to represent the value of a function. It has various applications in engineering and science, that are used to construct new data points within the range of a discrete data set of known data points or can be used for determining a formula…
