Project 2

CREATE COMPLETE TAIL LAMP USING HOT PLATE WELDING SECTION:











Lens Rib hight - MINIMUM 8-10 MM

Interferance - 1.5 MM

Thickness of Lens - 2.5 MM

Housing Thickness - 2 MM

Reflector Thickness - 2 MM

Boss - M4X10 SCREW

Positive Mounting for Lamp  - M5 SCREW

Create Wiring harness with wire routings

Create Clip Mounting and Stud Mounting Features

Prepare the Assembly and the Child Part drawing for the taillamp

Prepare a report for the Taillamp with all the Design parameter and feature explained and with relevant images

NOTE : This surface is not good and I will try to agene by agene do the work but this surface is very bad and live session to help  technician  that  I summitted this project with work on class a,b,c make
